Brand new AS-PL Starter motor drive
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 111.60 including GST
NZ$ 97.04 excluding GST
or four payments of $27.90
with
Learn More
each
SD6047
1
Associated Numbers
0280005000 0280007730 0280007731 0280007732 1280006860 1280006861 DEN-028300-1812 Denso Drive AssemblyCONDITION New ROTATION DIRECTION Clockwise GEAR OD 1.374" 34.900mm LENGTH 146.600 mm 5.772" NUMBER OF TEETH 9 SPLINES 10 TYPE Spiral DRIVE Roller & Reduction Gear WET CLUTCH SEAL FALSE 2.185" 55.500mm 35 028000-5000 PartELECTRIC STARTER Offset (OSGR) FAMILY R HP 3.353 POWER 2.500 kw VOLT 12 028000-5001 028000-7730 028000-7731 028000-7732 028000-7733 028000-7733ELECTRIC 028300-1810 AssemblyDRIVE 028300-1811 028300-5871 AssemblyNUMBER 028300-5872 128000-3361 StarterELECTRIC 4.023 3 128000-6860 128000-6861 128000-9491 128000-9492 428000-4860 PartCONDITION ELECTRIC 15451-63013 Kubota 15451-63014 15481-63013 15707-63012Specifications
| Length (L.1) | 146.50 mm |
| Length (L.2) | 29.40 mm |
| No./Splines | 10 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Outside Diameter (O.D.1) | 57.90 mm |
| Outside Diameter (O.D.2) | 35.20 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Type | Drive |
| Unit Type | DENSO |
Reference Information
| 028300-1810 | DENSO |
| 028300-1812 | DENSO |
| 136315 | CARGO |
| 15451-63041 | KUBOTA |
| CQ2010934 | CQ |
| DRV6109 | ELECTROLOG |
| F032136315 | CARGO |
| SDV32673 | WOODAUTO |
