Associated Numbers
S9277 65.26201-7077 S9277 65.26201-7077Specifications
| B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 mm |
| Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
| Coil Bolt Length | 19.5 mm |
| Inside Diameter (I.D.1) | 26 mm |
| L.B+ | 26.7 mm |
| Length (L.1) | 86.9 mm |
| Outside Diameter (O.D.1) | 55.5 mm |
| Outside Diameter (O.D.2) | 49 mm |
| Type | Solenoid |
| Unit Type | DAEWOO |
| Voltage | 24 V |
Reference Information
