Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 385.48 including GST
NZ$ 335.20 excluding GST
or four payments of $96.37
with
Learn More
each
A0788S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Information
0124225002Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 33.50 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.50 mm |
| Diameter (D.3) | 10.50 mm |
| Length (L.1) | 171 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56.50 mm |
| OEM Product | No |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 55 mm |
| Pulley Type | Solid |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| OPEL | Astra 1.4 Classic | [Z14XE] | 01.2004-12.2009 |
| OPEL | Astra 1.8 | [Z18XE] | 01.2004-12.2010 |
| OPEL | Astra 1.8 | [Z18XE] | 01.2005-12.2006 |
| OPEL | Astra 1.8 GTC | [Z18XE] | 01.2005-12.2006 |
| OPEL | Astra F 1.8 i | [X18XE1] | 01.1998-12.2000 |
| OPEL | Astra F 2.0 i | [X20XEV] | 01.1998-12.2000 |
| OPEL | Astra G 1.4 | [X14XE] | 01.1998-12.2000 |
| OPEL | Astra G 1.4 | [Z14XE] | 01.2000-12.2009 |
| OPEL | Astra G 1.4 Classic 16V | [X14XE] | 01.2004-12.2009 |
| OPEL | Astra G 1.6 | [C16SEL] | 01.1998-12.2005 |
| OPEL | Astra G 1.6 | [X16SZR] | 01.1998-12.2000 |
| OPEL | Astra G 1.6 | [X16XEL] | 01.1998-12.2000 |
| OPEL | Astra G 1.6 | [Z16SE] | 01.2000-12.2004 |
| OPEL | Astra G 1.6 | [Z16XE] | 01.2000-12.2004 |
| OPEL | Astra G 1.6 | [Z16YNG] | 01.2002-12.2004 |
| OPEL | Astra G 1.8 | [X18XE1] | 01.1998-12.2000 |
| OPEL | Astra G 1.8 | [Z18XE] | 01.2000-12.2005 |
| OPEL | Astra G 1.8 | [Z18XE] | 01.2001-12.2005 |
| OPEL | Astra G 2.0 | [X20XER] | 01.1999-12.2002 |
| OPEL | Astra G 2.0 | [X20XEV] | 01.1998-12.2004 |
| OPEL | Astra H 1.8 | [Z18XE] | 01.2004-12.2009 |
| OPEL | Combo C 1.6 | [Z16SE] | 01.2001-12.2004 |
| OPEL | Corsa C 1.4 | [Z14XE] | 01.2000-12.2003 |
| OPEL | Corsa C 1.6 | [Z16SE] | 01.2003-12.2005 |
| OPEL | Corsa C 1.8 16V | [Z18XE] | 01.2001-12.2006 |
| OPEL | Meriva A 1.6 | [Z16SE] | 01.2003-12.2005 |
| OPEL | Meriva A 1.6 16V | [Z16XE] | 01.2003-12.2006 |
| OPEL | Meriva A 1.8 | [Z18XE] | 01.2003-12.2010 |
| OPEL | Zafira A 1.6 16V | [X16XEL] | 01.1999-12.2000 |
| OPEL | Zafira A 1.6 16V | [X16XEL] | 01.1999-12.2005 |
| OPEL | Zafira A 1.8 16V | [Z18XEL] | 01.1999-12.2005 |
| VAUXHALL | Astra 1.4 | [X14XE] | 01.1999-12.2003 |
| VAUXHALL | Astra 1.6 | [X16SZR] | 01.1998-12.2000 |
| VAUXHALL | Astra 1.6 | [Z16SE] | 01.2000-12.2004 |
| VAUXHALL | Astra 1.8 | [Z18XE] | 01.2002-12.2003 |
| VAUXHALL | Astra 1.8 | [Z18XE] | 01.2002-12.2004 |
| VAUXHALL | Astra G 1.4 16V | [X14XE] | 01.1998-12.2003 |
| VAUXHALL | Astra G 1.6 | [Z16SE] | 01.2000-12.2005 |
| VAUXHALL | Astra G 1.6 | [Z16XE] | 01.1999-12.2004 |
| VAUXHALL | Astra G 1.6 16V | [X16XE] | 01.1998- |
| VAUXHALL | Astra G 1.6 Dualfuel | [X16SZR] | 01.1998-12.2000 |
| VAUXHALL | Astra G 1.8 | [X18XE1] | 01.1998-12.2004 |
| VAUXHALL | Astra G 1.8 | [Z18XE] | 01.2002-12.2003 |
| VAUXHALL | Astra G 2.0 | [X20XEV] | 01.1998- |
| VAUXHALL | Astra H 1.8 | [Z18XE] | 01.2004-12.2008 |
| VAUXHALL | Astra H 1.8 | [Z18XE] | 01.2004-12.2009 |
| VAUXHALL | Astravan G 1.4 16V | [X14XE] | 01.2000-12.2005 |
| VAUXHALL | Astravan G 1.6 i | 01.1998- | |
| VAUXHALL | Combo C 1.6 | [Z16SE] | 01.2001-12.2004 |
| VAUXHALL | Corsa C 1.4 16V | [Z14XE] | 01.2000- |
| VAUXHALL | Corsa C 1.6 | [Z16SE] | 01.2001-12.2004 |
| VAUXHALL | Corsa C 1.8 16V | [Z18XE] | 01.2000- |
| VAUXHALL | Zafira A 1.6 | [X16EL] | 01.1999-12.2005 |
| VAUXHALL | Zafira A 1.8 | 01.1999- | |
| VAUXHALL | Zafira A 2.0 DTi | [Y20DTH] | 01.2000- |
| VAUXHALL | Zafira B 1.6 | [Z16YNG] | 01.2005- |
Reference Information
| 0124225002 | BOSCH |
| 0124225024 | BOSCH |
| 0124225046 | BOSCH |
| 0124225050 | BOSCH |
| 09114931 | OPEL |
| 0986041260 | BOSCH |
| 111990 | CARGO |
| 1204123 | OPEL |
| 1204126 | OPEL |
| 13156051 | OPEL |
| 135.519.070 | PSH |
| 1516460R | DAF |
| 2015289.1 | SANDO |
| 20179982OE | REAL |
| 210352 | ERA |
| 21404R | WAI / TRANSPO |
| 24463063 | OPEL |
| 24463063YH | OPEL |
| 28-3657 | ELSTOCK |
| 301391RI | KUHNER |
| 35215230 | PRESTOLITE |
| 441538 | LOGISTIK |
| 4597 | CEVAM |
| 56787 | EAI |
| 6204076 | OPEL |
| 6204155 | OPEL |
| 6204192 | OPEL |
| 6204243 | OPEL |
| 90133600 | OPEL |
| 90133600 | VAUXHALL |
| 90561970 | OPEL |
| 90561970 | VAUXHALL |
| 9114931 | OPEL |
| 9117931 | OPEL |
| 9129823 | OPEL |
| 9133599 | OPEL |
| 913360 | FIAT |
| 9133600 | OPEL |
| 9133601 | OPEL |
| 9192823 | OPEL |
| 9192826 | OPEL |
| 93175795 | HOLDEN |
| 93175795 | OPEL |
| 93175942 | OPEL |
| 93180415 | OPEL |
| 93180415 | VAUXHALL |
| 93183891 | OPEL |
| 93183891 | VAUXHALL |
| 93189246 | OPEL |
| 93189246 | VAUXHALL |
| 93189266 | OPEL |
| 9512180 | OPEL |
| 9512783 | OPEL |
| 95521457 | OPEL |
| ALB1391 | KRAUF |
| ALT1366 | ELECTROLOG |
| ALTS769 | 3EFFE |
| CA1391IR | HC PARTS |
| CAL15289GS | CASCO |
| DRB1260 | DELCO |
| F032111990 | CARGO |
| LRB00404 | LUCAS |
| LRB404 | LUCAS |
| PRAS769 | 3EFFE |
| R1530035 | VAUXHALL |
| R1530035 | OPEL |
| R1530082 | OPEL |
| R1530082 | VAUXHALL |
| STA0514R | BOVEZ |
| STX100097 | STARDAX |
| STX100097R | STARDAX |
| STX100319 | STARDAX |
| STX100389 | STARDAX |
| STX100389R | STARDAX |
| STX100433 | STARDAX |
| STX100433R | STARDAX |
| STX100781 | STARDAX |
| STX101507 | STARDAX |
