Brand new AS-PL Alternator
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 737.97 including GST
NZ$ 641.71 excluding GST
or four payments of $184.49
with
Learn More
each
A3485S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
Information
FG15S046Specifications
| Amp | 150 A |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 8.50 mm |
| Diameter (D.3) | 9.50 mm |
| Length (L.1) | 187 mm |
| Mount Inside Length or Pad Mount C-C (C) | 68 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 41.50 mm |
| Pad mount thickness (E.2) | 41.50 mm |
| Plug Code | PL_2305 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 52 mm |
| Pulley to Mount Distance (A) | 75.50 mm |
| Pulley Type | Clutch |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Focus 2.0 Ti | [MGDA] | 01.2010-12.2011 |
| FORD | Focus 2.0 Ti | [XQDA] | 01.2010-12.2011 |
Reference Information
| 11618N | WAI / TRANSPO |
| 12090888 | EUROTEC |
| 1703864 | FORD |
| 2015A38.0 | SANDO |
| 2017983ABN | REAL |
| 2610970 | VALEO |
| 2610970A | VALEO |
| 28-6881 | ELSTOCK |
| 553834RI | KUHNER |
| 57626 | EAI |
| 595.594.150 | PSH |
| 595.594.150.008 | PSH |
| 89215841 | POWERMAX |
| 90-22-5651 | WILSON |
| A-9558 | DIXIE |
| ALTE648 | 3EFFE |
| ALV2200 | KRAUF |
| BV6N-10300-DB | FORD |
| CAL15A38AS | CASCO |
| CV6Z10346B | FORD |
| DA2373 | DELCO |
| DRA1263 | DELCO |
| FG15S046 | VALEO |
| LRA03771 | LUCAS |
| LRA3771 | LUCAS |
| PRAE648 | 3EFFE |
| UD17162A | AS-PL |
Video/Publications
