Brand new AS-PL Alternator
STANDARD LINE
AS-PL
VALEO
Price:
NZ$ 835.84 including GST
NZ$ 726.82 excluding GST
or four payments of $208.96
with
Learn More
each
AAM-C6023
A3486S
No stock in NZ - Call us for possible procurement options
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Specifications
- Vehicle Applications
- Alternatives >>>
- Reference Information
- Video/Publications
Information
FG20S015Specifications
| Amp | 180 A |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | 8.50 mm |
| Diameter (D.4) | 8.50 mm |
| Length (L.1) | 195 mm |
| Mount Inside Length or Pad Mount C-C (C) | 56 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 70 mm |
| Pad mount thickness (E.2) | 70 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 56 mm |
| Pulley to Mount Distance (A) | 29 mm |
| Pulley Type | Clutch |
| Unit Type | VALEO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AUDI | A4 1.8 TFSi | [CDHA] | 01.2013- |
| AUDI | A4 1.8 TFSi | [CJEB] | 01.2013- |
| AUDI | A4 1.8 TFSi Quattro | [CJEB] | 01.2013- |
| AUDI | A4 2.0 TFSi | [CADA] | 01.2008- |
| AUDI | A4 2.0 TFSi | [CAEA] | 01.2008- |
| AUDI | A4 2.0 TFSi | [CAEB] | 01.2008- |
| AUDI | A4 2.0 TFSi | [CDNB] | 01.2008- |
| AUDI | A4 2.0 TFSi | [CDNC] | 01.2008- |
| AUDI | A4 2.0 TFSi | [CDZA] | 01.2008- |
| AUDI | A4 2.0 TFSi Quattro | [CDNC] | 01.2008- |
| AUDI | A5 1.8 TFSi | [CJEE] | 01.2015-12.2016 |
| AUDI | A5 2.0 TFSi | [CNCE] | 01.2015-12.2016 |
| AUDI | A5 2.0 TFSi Quattro | [CNCE] | 01.2015-12.2016 |
| AUDI | A5 2.0 TFSi Quattro | [CPMB] | 01.2012-12.2016 |
| AUDI | A6 2.0 TFSi | [CAEB] | 01.2011- |
| AUDI | A6 2.0 TFSi | [CAEB] | 01.2011-12.2013 |
| AUDI | A6 2.0 TFSi | [CDNB] | 01.2011- |
| AUDI | A6 2.0 TFSi Quattro | [CAEB] | 01.2012-12.2013 |
| AUDI | Q5 2.0 TFSi Quattro | [CNCE] | 01.2015-12.2016 |
| AUDI | Q5 2.0 TFSi Quattro | [CPMB] | 01.2013-12.2016 |
Alternatives >>>
AAM-C6023 +Plus Line PRO Version
Reference Information
| 06H903016T | VW |
| 06H903017D | VW |
| 06H903017DX | VW |
| 06H903017K | VW |
| 06H903017KX | VW |
| 06H903018M | VW |
| 06H903018M | PORSCHE |
| 06H903018MX | VW |
| 06H903018MX | PORSCHE |
| 11706N | WAI / TRANSPO |
| 12090677 | EUROTEC |
| 2015011.1 | SANDO |
| 20179110OE | REAL |
| 205.563.200 | PSH |
| 205.563.200.004 | PSH |
| 205.563.200.346 | PSH |
| 205.563.200.460 | PSH |
| 205.563.200.608 | PSH |
| 209192 | ERA |
| 28-6504 | ELSTOCK |
| 4150 | CEVAM |
| 439798 | VALEO |
| 440438 | VALEO |
| 553456RIV | KUHNER |
| 6H903017K | VW |
| 6H903017K | PORSCHE |
| 6H903017KX | PORSCHE |
| 6H903017KX | VW |
| 6H903018M | VW |
| 6H903018M | PORSCHE |
| 6H903018MX | VW |
| 6H903018MX | PORSCHE |
| 90-22-5690 | WILSON |
| 9090763 | FRIESEN |
| A12VA0758AS | SIDAT |
| A-9605 | DIXIE |
| ALT00659 | ELECTROLOG |
| ALTE481 | 3EFFE |
| ALTE794 | 3EFFE |
| ALV3798 | KRAUF |
| CAL15011GS | CASCO |
| FG18T063 | VALEO |
| FG20S015 | VALEO |
| FGN15S015 | VALEO |
| L06H903017K | VW |
| LR1180-853 | HITACHI |
| LRA03392 | LUCAS |
| LRA3392 | LUCAS |
| PAC903018 | PORSCHE |
| PAC-903-018 | PORSCHE |
| STX102167 | STARDAX |
| UD17229A | AS-PL |
| VAL439798 | WOODAUTO |
Video/Publications
A3486SView your shopping basket or Browse other items in Alternators.
