Brand new AS-PL Alternator
STANDARD LINE
AS-PL
MAGNETI MARELLI
Price:
NZ$ 336.27 including GST
NZ$ 292.41 excluding GST
or four payments of $84.07
with
Learn More
each
A4131S
1
Information
63377008Specifications
| Amp | 70 A |
| Diameter (D.1) | 9 mm |
| Diameter (D.2) | 9 mm |
| Diameter (D.3) | 9 mm |
| Length (L.1) | 185 mm |
| Mount Inside Length or Pad Mount C-C (C) | 50 mm |
| OEM Product | No |
| Pad mount thickness (E.1) | 24 mm |
| Pad mount thickness (E.2) | 24 mm |
| Plug Code | PL_9104 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 5 qty |
| Pulley Outside Diameter (O.D.1) | 54 mm |
| Pulley to Mount Distance (A) | 16.50 mm |
| Pulley Type | Solid |
| Unit Type | MAGNETI MARELLI |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | C4 2.0 16V | [RFN(EW10J4)] | 11.2004- |
| FIAT | Albea 1.2 i.e. 16V | [188A5.000] | 01.2002- |
| FIAT | Albea 1.2 i.e. 8V | [188A4.000] | 01.2002- |
| FIAT | Albea 1.4 | [350A1.000] | 01.2007- |
| FIAT | Fiorino 1.4 | [350A1.000] | 10.2009- |
| FIAT | Fiorino 1.4 Natural Power | 06.2008- | |
| FIAT | Grande Punto 1.2 | [199A.4000] | 10.2005- |
| FIAT | Grande Punto 1.4 | [350A1.000] | 04.2008- |
| FIAT | Grande Punto 1.4 | [350A1.000] | 10.2005- |
| FIAT | Grande Punto 1.4 LPG | [350A1.000] | 03.2009- |
| FIAT | Grande Punto 1.4 Natural Power | [350A1.000] | 07.2008- |
| FIAT | Idea 1.4 | [350A1.000] | 10.2005- |
| FIAT | Palio 1.2 Flexfuel | [188A4.000] | 07.1997-08.2002 |
| FIAT | Palio 1.2 LPG | [188A4.000] | 07.1997-08.2002 |
| FIAT | Panda 1.1 | [187A.1000] | 09.2003- |
| FIAT | Panda 1.2 | [188A.4000] | 09.2003- |
| FIAT | Panda 1.2 | [188A4.000] | 09.2004- |
| FIAT | Panda 1.2 4x4 | [169A4.000] | 09.2010- |
| FIAT | Panda 1.2 4x4 | [188A4.000] | 10.2004- |
| FIAT | Panda 1.2 LPG | [169A4.000] | 06.2012- |
| FIAT | Panda 1.2 LPG | [188A4.000] | 04.2009- |
| FIAT | Panda 1.2 Natural Power | [188A4.000] | 01.2007-11.2009 |
| FIAT | Panda 1.2 X | [188A4.000] | 09.2004- |
| FIAT | Panda 1.4 BiFuel | [350A1.000] | 01.2010- |
| FIAT | Panda 1.4 D Bi-Power | [350A1.000] | 01.2007- |
| FIAT | Panda 1.4 Natural Power | [350A1.000] | 01.2007- |
| FIAT | Punto 1.2 | [188A4.000] | 02.2000- |
| FIAT | Punto 1.2 | [188A4.000] | 09.1999- |
| FIAT | Punto 1.2 | [199B9.000] | 02.2014- |
| FIAT | Punto 1.2 16V | [188A5.000] | 09.1999- |
| FIAT | Punto 1.2 BiFuel | [188A4.000] | 08.2007- |
| FIAT | Punto 1.2 Natural Power | [188A4.000] | 09.2003- |
| FIAT | Punto 1.4 | [199A7.000] | 03.2012- |
| FIAT | Punto 1.4 | [350A1.000] | 03.2012- |
| FIAT | Punto 1.4 | [843A1.000] | 09.2003- |
| FIAT | Punto 1.4 LPG | [350A1.000] | 03.2009- |
| FIAT | Punto Evo 1.2 | [169A.4000] | 10.2009- |
| FIAT | Qubo 1.4 | [350A1.000] | 10.2009- |
| FIAT | Siena 1.4 | [199A1.000] | 11.2007- |
| FIAT | Siena 1.4 | [350A1.000] | 01.2007- |
| FIAT | Strada 1.2 | [188A4.000] | 04.2003- |
| LANCIA | Musa 1.4 | [350A1.000] | 09.2005- |
| LANCIA | Musa 1.4 | [843A1.000] | 10.2004- |
| LANCIA | Y 1.2 | [188A4.000] | 03.1996-09.2003 |
| LANCIA | Y 1.2 | [840A3.000] | 03.1996-09.2003 |
| LANCIA | Y 1.2 16V | [188A5.000] | 10.2000-09.2003 |
| LANCIA | Ypsilon 1.2 Bifuel | [169A4.000] | 05.2011- |
| RENAULT | Grand Scenic 1.9 DCi | [F9Q812] | 04.2004- |
| RENAULT | Grand Scenic 1.9 DCi | [F9Q816] | 05.2005- |
| RENAULT | Grand Scenic 1.9 DCi | [F9Q818] | 05.2005- |
| RENAULT | Grand Scenic 1.9 DCi | [F9QEE804] | 05.2005- |
| RENAULT | Grand Scenic 1.9 DCi | [F9QJ803] | 05.2005- |
Reference Information
| 1022118230 | DENSO |
| 1022118430 | DENSO |
| 1022118431 | DENSO |
| 1022118432 | DENSO |
| 1022118440 | DENSO |
| 113718 | CARGO |
| 2030171.0 | SANDO |
| 2030171.1 | SANDO |
| 210659 | ERA |
| 210661 | ERA |
| 28-4889 | ELSTOCK |
| 301766RI | KUHNER |
| 301766RID | KUHNER |
| 301766RIV | KUHNER |
| 46542889 | FIAT |
| 46843091 | FIAT |
| 4750 | CEVAM |
| 505.532.070 | PSH |
| 505.532.070.460 | PSH |
| 505.532.070.605 | PSH |
| 51709133 | FIAT |
| 51714794 | FIAT |
| 5174794 | FIAT |
| 51859037 | FIAT |
| 52003531 | FIAT |
| 56932 | EAI |
| 63321718 | MAGNETI MARELLI |
| 63377002 | MAGNETI MARELLI |
| 63377006 | MAGNETI MARELLI |
| 63377006010 | MAGNETI MARELLI |
| 63377008 | MAGNETI MARELLI |
| 71783770 | FIAT |
| 71784028 | FIAT |
| 71793972 | FIAT |
| 71793973 | FIAT |
| 71795808 | FIAT |
| 89213739 | POWERMAX |
| 8EL012428-381 | HELLA |
| A12DE1139A2 | SIDAT |
| A133.399 | PSH |
| A146.554 | PSH |
| A149.835 | PSH |
| A4131S | AS-PL |
| AAL1790 | APEC |
| AG0225 | GHIBAUDI |
| ALE1766 | KRAUF |
| ALT2640 | SIOM |
| ALT321710 | SIOM |
| ALT321870 | SIOM |
| ALT6133 | ELECTROLOG |
| ALTE144 | 3EFFE |
| ALTL147 | 3EFFE |
| ALTS716 | 3EFFE |
| ANM32227X | ANDEL |
| CA1766IR | HC PARTS |
| CAL30171AS | CASCO |
| CAL30171GS | CASCO |
| DAN517 | DENSO |
| DRA0007 | DELCO |
| F032113718 | CARGO |
| LRA02545 | LUCAS |
| LRA2545 | LUCAS |
| MS1022118430 | DENSO |
| NPANAL1790 | NAPA |
| STX100018 | STARDAX |
| STX100018R | STARDAX |
| UD17203A | AS-PL |
| UD17203S | AS-PL |
| UD20819A | AS-PL |
