Specifications
Amp | 150 A |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 10 mm |
Diameter (D.3) | 12 mm |
Grooves | 6 qty |
Length (L.1) | 183 mm |
Mount Inside Length or Pad Mount C-C (C) | 75 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 59 mm |
Pad mount thickness (E.1) | 75 mm |
Pad mount thickness (E.2) | 75 mm |
Plug Code | PL_3402 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 30 mm |
Pulley Type | SOLID |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | Escape 3.0 | 01.2009-12.2012 | |
FORD | Fusion 3.0 | 01.2010-12.2012 | |
MAZDA | Tribute 3.0 | 01.2009-12.2011 | |
MERCURY | Mariner 3.0 | 01.2009-12.2011 | |
MERCURY | Milan 3.0 | 01.2010-12.2011 |
Reference Information
A002TX0391 A002TX0391ZC A2TX0391ZC UD20724A 90-27-3405 11411N A-80519 9L8T10300AC 9L8T10300AB 9L8Z10300A A5395S 595.964.150 9L8Z10346A A2TX0391 ALM2464 BE5T10300AAVideo/Publications
11411N 595.964.150 90-27-3405 9L8T10300AB 9L8T10300AC 9L8Z10300A 9L8Z10346A A-80519 A002TX0391 A002TX0391ZC A2TX0391 A2TX0391ZC ALM2464 BE5T10300AA UD20724AAdd Your Number
