Specifications
| Amp | 70 A |
| Bottom Mounting Foot Width (B) | 58 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10 mm |
| Grooves | 4 qty |
| Length (L.1) | 161 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 58 mm |
| Plug Code | PL_4504 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 90 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HONDA | Civic 1.5 i 16V | [D15B2] | 10.1991-11.1995 |
| HONDA | Civic 1.5 i 16V | [D15Z1] | 10.1991-11.1995 |
Reference Information
LRA01747 ALT6170 A5T06391ZC A5T04292ZC 31100P76003 2040359.2 ALT30401 101211-0300 31100P04G05 31100P04G03 31100P04G02 A5T06491ZC 31100P04G034 111285 90-29-5207N CAL40359AS 100211-9770 A005T04292ZC 20132953BN AHGA17 CAL40359RS CGB-13028 AHGA18 AHGA19 A5T06491 A5T06291 31100P08004 13509N A005T04292 JA980IR A005T06491ZC ALM0980 ALN0980 20132953RC UD17116A CGB-13117 2040359 ALTW055 31100-P08-003 31100P08014 A-8456 LRA1747 CJQ21 CJQ20 ALT121250 90-29-5207 89212767 A5T04292 A5T06391 A5T04092 31100P08024 101211-0250 28-3537 A005T06491 31100-P08-013 31100P05C04 ALT6393Video/Publications
100211-9770 101211-0250 101211-0300 111285 13509N 20132953BN 20132953RC 2040359.0 2040359.2 28-3537 31100-P08-003 31100-P08-013 89212767 90-29-5207 90-29-5207N A-8456 A005T04292 A5T04292 A5T06491ZC AHGA19 ALM0980 ALN0980 ALT121250 ALT30401 ALT6170 ALTW055 CAL40359AS CAL40359RS CGB-13028 CGB-13117 CJQ21 JA980IR LRA01747 LRA1747 UD17116AAdd Your Number
