Specifications
| Amp | 115 A |
| Bottom Mounting Foot Width (B) | 18.5 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | M10x1.25 mm |
| Grooves | 6 qty |
| Length (L.1) | 176 mm |
| Mount Inside Length or Pad Mount C-C (C) | 37 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 67 mm |
| Plug Code | PL_2306 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 29 mm |
| Pulley Type | CLUTCH |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| CITROEN | C1 1.0 VTi | [CFB(1KR)] | 04.2014- |
| PEUGEOT | 108 1.0 VTi | [CFB(1KR)] | 05.2014- |
| TOYOTA | Aygo 1.0 | [1KR-FE] | 05.2014- |
Reference Information
2040483.1 ALN1278 89216435 554641RI 104211-3480 27060-0Q170 1612352080 104211-3481 40205 B000912180 554641RID ALT6805 DAN1319 A6628S 270600Q17084 UD90361A 28-7564 J5112218 B000921280 CAL40483GS LRA03954 DENDAN1319 021080-2370 20132384OE 57514 LRA3954 DA2568 RNL104211-3480 DRA1458 225.539.100.260 225.539.100.261Video/Publications
104211-3480 1612352080 20132384OE 2040483.1 225.539.100 27060-0Q170 28-7564 40205 554641RI 554641RID 57514 A6628S ALN1278 B000912180 CAL40483GS DA2568 DAN1319 DENDAN1319 DRA1458 J5112218 LRA03954 LRA3954 RNL104211-3480 UD90361AAdd Your Number
