Specifications
| Amp | 80 A |
| Bottom Mounting Foot Width (B) | 10.5 mm |
| Diameter (D.1) | M8x1.25 mm |
| Diameter (D.2) | 8 mm |
| Diameter (D.3) | 8.5 mm |
| Grooves | 1 qty |
| Groove Width (W.1) | 11 mm |
| Length (L.1) | 177 mm |
| Mount Inside Length or Pad Mount C-C (C) | 85 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 41.5 mm |
| Outside Diameter (O.D.2) | 68 mm |
| Plug Code | PL_9105 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 38 mm |
| Pulley Type | SOLID |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| AGCO | LT70 3.9 | 01.2002-12.2004 | |
| AGCO | LT85 3.9 | 01.2002-12.2003 | |
| CHALLENGER | MT345 3.3 | 01.2006-12.2009 | |
| MASSEY FERGUSON | 3615 3.3 | [33DT] | 01.2007-12.2011 |
| MASSEY FERGUSON | 3625 3.3 | [33DT] | 01.2007-12.2011 |
| MASSEY FERGUSON | 3635 3.3 | [33DT] | 01.2007-12.2011 |
| MASSEY FERGUSON | 3645 3.3 | [33DTA] | 01.2007-12.2011 |
Reference Information
IA1227 755.006.080 3823653M1 11.203.375 20119722OE 282-30360 CAL21227GS 2560 205804 LRA3385 MG161 LRA03385 116111 554347RI 28-5997 AAK4336 MAHMG161 72735160 554347RIL UD17139A ALI2186 ALT79341 A-6591 2021227.1Video/Publications
11.203.375 116111 20119722OE 2021227.1 205804 2560 28-5997 282-30360 3823653M1 554347RI 554347RIL 72735160 755.006.080 A-6591 AAK4336 ALI2186 CAL21227GS IA1227 LRA03385 LRA3385 MAHMG161 UD17139AAdd Your Number
