Specifications
Kilowatt | 3.6 kW |
Length (L.1) | 385 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 127 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 47.5 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | BOSCH |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
VOLVO PENTA | Engine | [AQD70] | 01.1976-12.1982 |
VOLVO PENTA | Engine | [MD42A] | 01.1977-12.1979 |
VOLVO PENTA | Engine | [MD70B] | 01.1970-12.1979 |
VOLVO PENTA | Engine | [TAMD70] | 01.1976-12.1986 |
VOLVO PENTA | Engine | [THAMD70] | 01.1976-12.1979 |
VOLVO PENTA | Engine | [TMD70] | 01.1977-12.1979 |
VOLVO PENTA | Engine 5.5 | [TAMD60] | 01.1976-12.1987 |
VOLVO PENTA | Engine 5.5 | [TAMD60B] | 01.1978-12.1983 |
VOLVO PENTA | Engine 5.5 | [TD60B] | 01.1978-12.1986 |
Reference Information
810.101.093.311 101030 1401023 51262017008 233991 0001401023 EAA-121535 88262016002 CST10175ES 810.101.093.390 0001401060 1401060 CST10175AS 33655 6010175 101030P 1413004 1304445 LRS1204 22804 CGB-11409 110538 20401571BN 19024005 0001413004 11.139.525 88212405 51262019008 810.101.093.016 111217 240500 810.101.093.010 240501 UD16935S 182-30362 CS1030 5710906 0001418009 STRS950 847306 842775 LRS01204 331949 881681 20401571EL 837924 PRSS950 STR50345 1418009 6010175.3 MS704 843511 25-1270 STB0108 5710993Video/Publications
PRSS950 0001401023 0001413004 0001418009 101030 101030P 11.139.094 11.139.525 110538 120-40170 19024005 20401571BN 20401571EL 22804 25-1270 260-46105 33655 6010175.0 6010175.3 71-15-18221 72736198 72741802 842775 843511 847306 860542 861067 88212405 8EA737247-001 91-15-6942 AZK5445 AZK5564 CS1030 CST10175AS CST10175ES EAA-121535 IS9085 LRS01204 LRS1204 MAHMS570 MS 570 MS704 PRE861067 STB0108 STR50345 STRS950 TS-6122 UD16935S 0001401060 BNG412CR238 810.101.093.010 810.101.093.311 233991 3803599 837924 881681 220244Add Your Number
