Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 198 mm |
Mount Hole Center - Center (O.1) | 100 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 12 qty |
Pinion at Rest (B) | 26 mm |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Genesis 3.8 GDi | [G6DJ] | 06.2014- |
HYUNDAI | Genesis 3.8 GDi 4WD | [G6DJ] | 06.2014- |
Reference Information
88214044 150.931.122 25-5225 S-1559 LRS4061 STD0497 UD17269S 8000497 91-01-4798 36100-3C240 LRS04061 STR2094Video/Publications
150.931.122 25-5225 36100-3C240 8000497 88214044 91-01-4798 LRS04061 LRS4061 S-1559 STD0497 UD17269SAdd Your Number
