Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 216 mm |
Mount Hole Center - Center (O.1) | 82 mm |
Mount Hole Diameter (C.1) | 10 mm |
Mount Hole Diameter (C.2) | 10 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 18.5 mm |
Rotation | CW |
Unit Type | DELCO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHEVROLET | Equinox 3.4 | 01.2007-12.2009 | |
CHEVROLET | Malibu 3.5 | 01.2007-12.2010 | |
CHEVROLET | Malibu 3.9 | 01.2006-12.2007 | |
PONTIAC | G6 3.5 | 01.2007-12.2010 | |
PONTIAC | G6 3.9 | 01.2006-12.2009 | |
PONTIAC | Torrent 3.4 | 01.2007-12.2009 | |
SATURN | Aura 3.5 | 01.2007-12.2008 | |
SATURN | Vue 3.5 | 01.2008-12.2010 |
Reference Information
6786R 0986CR1804 91-01-4691 0000986CR1804 8000064 91-01-4691N S-1497 UD20582S 89017755 12594495 6786NVideo/Publications
0986CR1804 12594495 6786N 6786R 8000064 89017755 91-01-4691 91-01-4691N S-1497 UD20582SAdd Your Number
