Specifications
Kilowatt | 4 kW |
Length (L.1) | 306 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 128 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
Mount Hole Diameter (C.3) | 10.5 mm |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 46 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DELCO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FIAT-ALLIS | FR128 | 01.2010-12.2013 | |
NEW HOLLAND | 7D.12C | 01.2010-12.2013 |
Reference Information
6060620.1 75259789 75327465 CST60620GS 201-29204 STD1743 UD18481S TS-1833 10479654 5L637 20409026OE 8200065Video/Publications
10479654 201-29204 20409026OE 6060620.1 75259789 75327465 8200065 CST60620GS STD1743 TS-1833 UD18481SAdd Your Number
