Specifications
Kilowatt | 0.9 kW |
Length (L.1) | 185 mm |
Mount Hole Center - Center (O.1) | 100 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 8 qty |
Pinion at Rest (B) | 15 mm |
Rotation | CW |
Spigot Diameter (A) | 75 mm |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | Grand i10 1.2 | [G4LA] | 12.2013- |
HYUNDAI | i10 1.2 | [G4LA] | 04.2011-12.2013 |
HYUNDAI | i10 1.2 | [G4LA] | 11.2008-12.2011 |
HYUNDAI | i10 1.2 | [G4LA] | 12.2013- |
HYUNDAI | i20 1.2 | [G4LA] | 03.2012-12.2015 |
HYUNDAI | i20 1.2 | [G4LA] | 09.2008-12.2012 |
KIA | Picanto 1.0 | [G3LA] | 05.2011- |
KIA | Picanto 1.0 Bi-Fuel | [B3LA] | 05.2011- |
KIA | Picanto 1.0 LPG | [B3LA] | 08.2013- |
KIA | Picanto 1.2 | [G4LA] | 09.2011- |
KIA | Rio 1.25 CVVT | [G4LA] | 09.2011-12.2017 |
KIA | Rio 1.25 CVVT | [G4LA] | 10.2011-12.2017 |
KIA | Rio 1.25 LPG | [G4LA] | 09.2011- |
KIA | Rio 1.2 CVVT | [G4LA] | 11.2014-12.2017 |
Reference Information
LRS2612 S12HY0772A2 S3082 DS1668 9767 12296 UD17090S 20493121OE RAS31669 STR8723 446500 DS1668N DRS0558 ANM12778X EAA-122806 STQ0902 UD20830S JM000A15001 TS9M1 1250902 36100-03150 6032121.1 88214379 254747 30350N LRS02612 36100-03200 36100-03400 150.570.082 STR0119 STV0902 220644 5015110 DRS0558N 26024242A 254747V 114760 336022 CST32121GS VAL600257 S12HY0772 25-4285 36100-03100 STR54167Video/Publications
114760 12296 1250902 150.570.082 20493121OE 220644 25-4285 254747 254747V 26024242A 30350N 36100-03100 36100-03150 36100-03200 36100-03400 6032121.1 88214379 9767 CST32121GS DRS0558 DRS0558N DS1668 DS1668N EAA-122806 JM000A15001 LRS02612 LRS2612 RAS31669 STQ0902 STR54167 STV0902 TS9M1 UD17090S VAL600257 S3082 UD20830SAdd Your Number
