Specifications
Kilowatt | 5 kW |
Length (L.1) | 287 mm |
Mount Hole Center - Center (O.1) | 23.5 mm |
Mount Hole Center - Center (O.2) | 43 mm |
Mount Hole Center - Center (O.3) | 144 mm |
Mount Hole Center - Center (O.4) | 102.5 mm |
Mount Hole Diameter (C.1) | M10x1.5 mm |
Mount Hole Diameter (C.2) | M10x1.5 mm |
Mount Hole Diameter (C.3) | 13 mm |
Mount Hole Diameter (C.4) | 13 mm |
No./Mount holes | 4 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 17 mm |
Rotation | CW |
Spigot Diameter (A) | 60 mm |
Unit Type | VALEO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | HD 72 3.9 | [D4DB] | 09.2006- |
HYUNDAI | HD 72 3.9 | [D4DC] | 09.2006- |
HYUNDAI | HD 78 3.9 | [D4DA] | 09.2006- |
Reference Information
CST32609GS 130-80203 20493906OE 151.545.114.000 UD18232S 6032609.1 PXPSA-806 STA4570 3610041100 3610045501 S3105S 600256 1250433 36100-45700 DRS1262Video/Publications
1250433 130-80203 151.545.114.000 36100-45700 600256 DRS1262 PXPSA-806 STA4570 UD18232SAdd Your Number
