Specifications
Kilowatt | 5 kW |
Length (L.1) | 289 mm |
Mount Hole Center - Center (O.1) | 43 mm |
Mount Hole Center - Center (O.2) | 144 mm |
Mount Hole Center - Center (O.3) | 102 mm |
Mount Hole Center - Center (O.4) | 24 mm |
Mount Hole Diameter (C.1) | M10x1.75 mm |
Mount Hole Diameter (C.2) | 12.5 mm |
Mount Hole Diameter (C.3) | 12.5 mm |
Mount Hole Diameter (C.4) | M10x1.75 mm |
No./Mount holes | 4 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 9 qty |
No./Teeth (Replaces) | 9 qty |
Pinion at Rest (B) | 18 mm |
Rotation | CW |
Spigot Diameter (A) | 60 mm |
Unit Type | VALEO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HYUNDAI | County | [D4DD] | |
HYUNDAI | HD 65 | [D4DD] | |
HYUNDAI | HD 72 | [D4DD] | |
HYUNDAI | HD 78 | [D4DD] |
Reference Information
PXPSA-807 UD14896S S0001250238 600250 STA3500 36100-45500 602037Video/Publications
36100-45500 600250 602037 PXPSA-807 S0001250238 STA3500 UD14896SAdd Your Number
