Specifications
Kilowatt | 2 kW |
Length (L.1) | 241 mm |
Mount Hole Center - Center (O.1) | 105 mm |
Mount Hole Center - Center (O.2) | 145 mm |
Mount Hole Center - Center (O.3) | 105 mm |
Mount Hole Diameter (C.1) | 14 mm |
Mount Hole Diameter (C.2) | 14 mm |
Mount Hole Diameter (C.3) | 14 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 23.5 mm |
Rotation | CW |
Spigot Diameter (A) | 100 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | Canter 2.7 D | [4DR51] | 01.1980-12.1989 |
Reference Information
20437291BN 4857-18-400 CGB-23085 M002T54271 M002T54272 6035192 140.017.093 CST35192AS 254101 88214837 130-20139 STM1550 BOM 103-236 UNIT 336218 LRS01598 STR71322 UD17034S M2T54271 M2T54272 MAV371920 ME007517 25-3116 ME007655 91-27-3214 ME007433 STRE027 LRS1598Video/Publications
130-20139 140.017.093 20437291BN 25-3116 254101 4857-18-400 6035192.0 88214837 91-27-3214 CGB-23085 CST35192AS LRS01598 LRS1598 M002T54271 M002T54272 M2T54271 M2T54272 MAV371920 ME007433 STM1550 STR71322 STRE027 UD17034S UNIT BOM 103-236Add Your Number
