Specifications
Kilowatt | 5 kW |
Length (L.1) | 311 mm |
Mount Hole Center - Center (O.1) | 151 mm |
Mount Hole Diameter (C.1) | 13.5 mm |
Mount Hole Diameter (C.2) | 13.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 65 mm |
Rotation | CW |
Spigot Diameter (A) | 110 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | Fuso FK 7.5 | [6D16-2AT] | 01.1998-12.2004 |
MITSUBISHI | Fuso FM 7.5 | [6D16-2AT] | 01.1998-12.2004 |
Reference Information
150.930.112 M9T50071 91-27-3296 18537N ME072979 UD16958S M009T50071 S-8805 STM1661 130-90100Video/Publications
130-90100 150.930.112 18537N 91-27-3296 M009T50071 M9T50071 ME072979 S-8805 STM1661 UD16958SAdd Your Number
