Specifications
Kilowatt | 5 kW |
Length (L.1) | 288 mm |
Mount Hole Center - Center (O.1) | 77 mm |
Mount Hole Center - Center (O.2) | 115 mm |
Mount Hole Center - Center (O.3) | 55 mm |
Mount Hole Center - Center (O.4) | 66 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | 13 mm |
Mount Hole Diameter (C.3) | 13 mm |
Mount Hole Diameter (C.4) | 13 mm |
No./Mount holes | 4 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 26 mm |
Rotation | CW |
Spigot Diameter (A) | 66 mm |
Unit Type | MITSUBISHI |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
MITSUBISHI | Fuso | [4M50] | |
MITSUBISHI | Fuso | [4M50T] | |
MITSUBISHI | Fuso | [4M50T1] |
Reference Information
M008T62371 ME223360 20437376OE 255473M 151.539.114.370 130-80138 M8T62371AM MITM8T62371 M008T62371AM 6035673.1 151.539.114.138 UD16956S CST35673GS M8T62371 STM3360 151.539.114.130Video/Publications
130-80138 151.539.114 20437376OE 255473M 6035673.1 CST35673GS M008T62371 M8T62371 ME223360 MITM8T62371 STM3360 UD16956SAdd Your Number
