Associated Numbers
S5431S.
S5438S.
S5469S.
Specifications
Kilowatt | 1.6 kW |
Length (L.1) | 228 mm |
Mount Hole Center - Center (O.1) | 104 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 15 qty |
Pinion at Rest (B) | 17 mm |
Rotation | CW |
Spigot Diameter (A) | 77 mm |
Unit Type | MITSUBISHI |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JOHN DEERE | 9410 | [6081HH] | 01.1988-12.1997 |
MITSUBISHI | L2A | [L2A-61DM] | |
MITSUBISHI | L2A | [L2A-61SS] | |
MITSUBISHI | L2A | [L2A-62SS] | |
MITSUBISHI | L2E | [L2E-61DM] | |
MITSUBISHI | L2E | [L2E-61HMG] | |
MITSUBISHI | L2E | [L2E-61SA] | |
MITSUBISHI | L2E | [L2E-61SS] | |
MITSUBISHI | L2E | [L2E-61TM] | |
MITSUBISHI | L2E | [L2E-62SS] | |
MITSUBISHI | L3E | [L3E-61HMG] | |
MITSUBISHI | L3E | [L3E-61SS] | |
MITSUBISHI | L3E | [L3E-61TM] | |
MITSUBISHI | L3E | [L3E-62SS] | |
TORO | Workman 1300D | [23.0HP] | 01.1998-12.1998 |
TORO | Workman 3300D | [21.0HP] | 01.1993-12.2001 |
TORO | Workman 3310D | [21.0HP] | 01.1999-12.2001 |
TORO | Workman 3320D | [21.0HP] | 01.1999-12.1999 |
TORO | Workman 4300D | [23.0HP] | 01.1995-12.2001 |
Reference Information
5035777 LRS1145 88213375 M2T50271 MM314604 130-10128 25-1109 S-8802 RNLM2T50281 M2T53681 MM317600 LRS01145 M002T50285 UD17045S MM317602 CST35154GS STRS612 6035154 20437451BN M002T50281 243-16108 CST35154AS 8844 20437451OE S12MH0562A2 015125-53001E 17097N MM31760401 150.908.152 5527658960 S5431S 112178 ALT322030 STR28006 M2T50281 MM317604 M2T50285 STR5262 6035154.1 M002T50271 M002T53681 MAV371540 91-27-3210 CGB-23049Video/Publications
112178 130-10128 150.908.152 17097N 20437451BN 20437451OE 243-16108 25-1109 6035154.0 6035154.1 88213375 8844 91-27-3210 ALT322030 CGB-23049 CST35154AS CST35154GS LRS01145 LRS1145 M002T50271 M002T50281 M002T50285 M002T53681 M2T50271 M2T50281 M2T50285 M2T53681 MAV371540 MM317600 MM317602 MM317604 RNLM2T50281 S-8802 STR28006 STRS612 UD17045SAdd Your Number
