Specifications
| Kilowatt | 1.6 kW |
| Length (L.1) | 193 mm |
| Mount Hole Center - Center (O.1) | 122 mm |
| Mount Hole Diameter (C.1) | M10x1.25 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 10 qty |
| Pinion at Rest (B) | 14 mm |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| TOYOTA | Yaris 1.3 16V | (NCP10_)[2NZ-FE] | 11.1999-10.2004 |
| TOYOTA | Yaris Verso 1.3 | (NCP22)[2NZ-FE] | 11.1999-09.2005 |
Reference Information
17842N 6E+11 MSN8057 986025620 DS1406 CS1499 428000-7830 20432613OE 428000-0020 STRS313 428000-0022 428000-0021 254582D 428000-0024 428000-0023 DRS0296 428000-0026 428000-0025 63280057010 25-4232 STR70285 6040316.1 190.598.102.050 88214076 DSN936 220927 STR6412 254582 PRSS313 114239 ANM12516X 000986025620 28100-21061 J5212104 28100-21062 28100-21060 28100-21063 LRS02560 CST40316GS LRS2560 63280057 190.598.102.260Video/Publications
20432613OE 254582D 28100-21060 28100-21061 28100-21062 428000-0024 428000-7830 6040316 CST40316GS DRS0296 DSN936 STR70285 220927Add Your Number
