Specifications
Kilowatt | 1.2 kW |
Length (L.1) | 190 mm |
Mount Hole Center - Center (O.1) | 139 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 1 qty |
No./Teeth | 9 qty |
Pinion at Rest (B) | 23.5 mm |
Rotation | CW |
Spigot Diameter (A) | 74 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | Auris 1.3 | [1NR-FE] | 07.2013- |
TOYOTA | Auris 1.3 | [1NR-FE] | 10.2012- |
TOYOTA | Corolla 1.3 | [1NR-FE] | 06.2013- |
TOYOTA | Verso S 1.3 | [1NR-FE] | 11.2010-10.2016 |
TOYOTA | Yaris 1.3 | [1NR-FE] | 09.2011- |
TOYOTA | Yaris 1.3 | [1NR-FKE] | 09.2011- |
TOYOTA | Yaris 1.3 VVTi | [1NR-FE] | 10.2012- |
TOYOTA | Yaris 1.5 | [2NR-FKE] | 03.2017- |
Reference Information
9664 CGB-55098 CST40299OS CST40299GS STR6581 20432992 28100-0Y100 28100-0Y101 LRS03928 428080-8440 5040619 DRS1181 20432992OE 428080-8445 DSN1009 CST40299 6040299.1 190.925.092 S12DE0594 S12DE0594A2 30569-OS 255260D DENDSN1009 UD15216S 25-5091 STN7440 LRS3928 428000-8440 28100-0Y090 28100-0Y091 28100-0Y290 428000-8442 428000-8441 DS2291 428000-8444 428000-8443 AEX1156 428000-7914 428000-7915 428000-7910 28100-47180 428000-7911 428000-7912 428000-7913 CST40299RS STN8440 9655 STRJ091 428000-8434 S6245S CST40299ES 428000-8431 428000-8430 428000-8433 428000-8432 CST40299AS 428000-7903 428000-7904 428000-7905 28100-47170 428000-7900 428000-7901 28100-47171 428000-7902Video/Publications
190.925.092 20432992 20432992OE 25-5091 255260D 28100-0Y090 28100-0Y091 28100-0Y100 28100-0Y101 28100-47170 28100-47171 28100-47180 30569-OS 428000-7900 428000-7901 428000-7902 428000-7903 428000-7904 428000-7905 428000-7910 428000-7911 428000-7912 428000-7913 428000-7914 428000-7915 428000-8430 428000-8431 428000-8432 428000-8433 428000-8434 428000-8440 428000-8441 428000-8442 428000-8443 428000-8444 428080-8440 428080-8445 6040299.1 9655 9664 AEX1156 CGB-55098 CST40299 CST40299AS CST40299ES CST40299GS CST40299OS CST40299RS DENDSN1009 DRS1181 DS2291 LRS03928 LRS3928 STN7440 STN8440 STRJ091 UD15216SAdd Your Number
