Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
DENSO
Price:
NZ$ 551.39 including GST
NZ$ 479.47 excluding GST
or four payments of $137.85
with
Learn More
each
S4042
S6248S
No stock in NZ currently
No stock in NZ currently
Information
428000-4920Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 229 mm |
| Mount Hole Center - Center (O.1) | 122 mm |
| Mount Hole Diameter (C.1) | M12x1.25 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 1 qty |
| No./Teeth | 11 qty |
| OEM Product | No |
| Pinion at Rest (B) | 24 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 74 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| LEXUS | IS 220 2.2 D | [2AD-FHV] | 10.2005- |
| LEXUS | IS 2.2 D | [2AD-FTV] | 07.2010- |
| TOYOTA | Auris 2.0 D-4D | [1AD-FTV] | 03.2007- |
| TOYOTA | Auris 2.2 D | [2AD-FHV] | 03.2007- |
| TOYOTA | Avensis 2.0 D-4D | [1AD-FTV] | 03.2006- |
| TOYOTA | Avensis 2.0 D-4D | [1AD-FTV] | 11.2011- |
| TOYOTA | Avensis 2.2 D-4D | [2AD-FTV] | 10.2005- |
| TOYOTA | Avensis 2.2 D-4D CAT | [2AD-FHV] | 07.2005- |
| TOYOTA | Corolla 2.2 D-4D | [2AD-FHV] | 11.2006- |
| TOYOTA | Corolla 2.2 D-4D Verso | [2AD-FTV] | 10.2005- |
| TOYOTA | RAV4 2.2 D-4D | [2AD-FHV] | 12.2008- |
| TOYOTA | RAV4 2.2 D-4D | [2AD-FTV] | 03.2006- |
| TOYOTA | RAV4 2.2 D-4D | [2AD-FTV] | 12.2008- |
| TOYOTA | RAV4 2.2 D-4D CAT | [2AD-FHV] | 03.2006- |
Reference Information
| 011-001-000660R | REMANTE |
| 063721369010 | MAGNETI MARELLI |
| 0986023240 | BOSCH |
| 10040249AV | ITAB AUTOMOTIVE |
| 10040249OV | ITAB AUTOMOTIVE |
| 10441284 | ALANKO |
| 106849 | FARCOM |
| 11040749 | EUROTEC |
| 114216 | CARGO |
| 12138050 | MTR |
| 12213 | EAI |
| 1648213380 | EUROREPAR |
| 190.571.112.050 | PSH |
| 190.571.112.260 | PSH |
| 190.571.112.440 | PSH |
| 190.571.112.500 | PSH |
| 1986S00924 | BOSCH |
| 201369 | KUHNER |
| 201369V | KUHNER |
| 20432942BN | REAL |
| 20432942OE | REAL |
| 20432942RE | REAL |
| 213ST21 | STARTCAR |
| 220664A | ERA |
| 25-3436 | ELSTOCK |
| 25-3436CT | AINDE |
| 28100-0G040 | TOYOTA |
| 28100-0R010 | TOYOTA |
| 28100-0R010-84 | TOYOTA |
| 28100-0R030 | TOYOTA |
| 28100-0R030-84 | TOYOTA |
| 28100-OG040 | TOYOTA |
| 3113836 | HENKEL PARTS |
| 3113837 | HENKEL PARTS |
| 3113840 | HENKEL PARTS |
| 33265N | WAI / TRANSPO |
| 335216112 | DRI |
| 336429 | LOGISTIK |
| 428000-3180 | DENSO |
| 428000-3181 | DENSO |
| 428000-3182 | DENSO |
| 428000-3183 | DENSO |
| 428000-4920 | DENSO |
| 428000-4921 | DENSO |
| 428000-4923 | DENSO |
| 428000-5710 | DENSO |
| 428000-5711 | DENSO |
| 428000-5712 | DENSO |
| 428000-5713 | DENSO |
| 428000-7730 | DENSO |
| 428000-7731 | DENSO |
| 428000-7732 | DENSO |
| 428000-7733 | DENSO |
| 4780310 | NK |
| 5040069 | MEAT & DORIA |
| 6040249.0 | SANDO |
| 6040249.1 | SANDO |
| 6040249.4 | SANDO |
| 803-17086 | IAP QUALITY PARTS |
| 8080257 | FRIESEN |
| 8212431 | POWERMAX |
| 88212431 | POWERMAX |
| 8EA012527-711 | HELLA |
| 944280802570 | MAGNETI MARELLI |
| 9732 | CEVAM |
| A79150 | ATL AUTOTECHNIK |
| ANM12508X | ANDEL |
| ASM1062 | APEC |
| AZMT-53-010-1196 | A.Z. MEISTERTEILE |
| BREF0320986023240 | CARWOOD GROUP |
| BREF032114216 | CARWOOD GROUP |
| BREF0321986S00924 | CARWOOD GROUP |
| BST2337 | BORG & BECK |
| CGB-23190 | AINDE |
| CST40249AS | CASCO |
| CST40249GS | CASCO |
| CST40249OS | CASCO |
| DRS0288 | DELCO |
| DSN984 | DENSO |
| EZ0063 | ELTA AUTOMOTIVE |
| F032114216 | CARGO |
| LES0510 | LE PART |
| LRS02265 | LUCAS |
| LRS2265 | LUCAS |
| MAV422490A | SIOM |
| MAV422490RS | SIOM |
| NPANSM1062 | NAPA |
| PRSJ001 | 3EFFE |
| RAS31399 | DELCO |
| RNL1369JS | RNL |
| RNL4280004920 | RNL |
| S102191 | BTS TURBO |
| S103173 | BTS TURBO |
| S12DE0088A2 | SIDAT |
| S131.515 | PSH |
| S6248S | AS-PL |
| SG0527 | GHIBAUDI |
| SG0527RB | GHIBAUDI |
| ST01470 | TMI |
| STM1099 | ROLLCO |
| STR6170 | ELECTROLOG |
| STR70287 | WOODAUTO |
| STRJ001 | 3EFFE |
| STV1369 | KRAUF |
| STX200226R | STARDAX |
| T001003036 | SEG AUTOMOTIVE |
| T001003041 | SEG AUTOMOTIVE |
| T001003044 | SEG AUTOMOTIVE |
| T521A130 | NPS |
| TO9072 | SNRA |
| TT16442 | TESLA TECHNICS |
| TT16442PRO | TESLA TECHNICS |
| UD17279S | AS-PL |
| WG1920262 | WILMINK GROUP |
| WG2013221 | WILMINK GROUP |
| WG2196754 | WILMINK GROUP |
| WOOSTR70287 | WOODAUTO |
Video/Publications
