Specifications
| Kilowatt | 1.4 kW |
| Length (L.1) | 189 mm |
| Mount Hole Center - Center (O.1) | 110 mm |
| Mount Hole Diameter (C.1) | 8.5 mm |
| Mount Hole Diameter (C.2) | 8.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| Pinion at Rest (B) | 18 mm |
| Rotation | CW |
| Spigot Diameter (A) | 66 mm |
| Unit Type | DENSO |
| Voltage | 24 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| KUBOTA | V1200 | 01.1987- |
Reference Information
CST40629GS CST40629 CST40629ES 128000-5411 128000-5410 CST40629AS CST40629OS RNL128000-5410 18143N UD14279S 336212 CST40629RS STN3204YJ STR30026 254209 19883-63012 19883-63011 691.502.092 16617-63011 113204 CGB-24780 190-20265 254209D 228000-4780 6040629 228000-4781 STN3204 STR6751 71-29-18143 91-29-5341Video/Publications
113204 128000-5410 128000-5411 16617-63011 18143N 190-20265 19883-63011 19883-63012 228000-4780 228000-4781 254209 254209D 6040629 691.502.092 71-29-18143 91-29-5341 CGB-24780 CST40629 CST40629AS CST40629ES CST40629GS CST40629OS CST40629RS RNL128000-5410 STN3204 STN3204YJ STR30026 UD14279SAdd Your Number
