Specifications
Kilowatt | 2.5 kW |
Length (L.1) | 295 mm |
Mount Hole Center - Center (O.1) | 125 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 88 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CUMMINS | T120C | [QSB5-G3] | |
CUMMINS | T180C | [QSB7-G3] | |
CUMMINS | T240C | [QSB7-G5] | |
CUMMINS | T70C | [QSB5-G1] | |
CUMMINS | T90C | [QSB5-G2] |
Reference Information
CST40332GS 20432233OE 640.518.102 S12DE0486A2 254396 336434 428080-2920 STR6680 5040592 STR70302 3971610 3971613 254396D 3971614 3971615 20432233BN 428000-2900 S-80229 246-25175 428000-2920 UD17011S 6040332.1 1654059 STN2911 190-25150 6040332 428080-2910 115352 428000-2870 19104N 8239 91-29-5683 CST40332AS 428000-2911 428000-2910Video/Publications
115352 190-25150 19104N 20432233BN 20432233OE 246-25175 254396 254396D 3971610 3971613 3971614 3971615 428000-2900 428000-2910 428000-2911 428000-2920 428080-2910 428080-2920 6040332.0 6040332.1 640.518.102 8239 91-29-5683 CST40332AS CST40332GS S-80229 STN2911 STR70302 UD17011SAdd Your Number
