Specifications
Kilowatt | 4.5 kW |
Length (L.1) | 295 mm |
Mount Hole Center - Center (O.1) | 90 mm |
Mount Hole Center - Center (O.2) | 125 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CUMMINS | Engine 5.9 |
Reference Information
254831D 3935200 DENDSN966 DSN966 6040643.1 CST40643GS 11040923 228000-8852 STN8850 228000-8851 228000-8850 STR6703 336304 3957595 STR70311 S6400S 19168N 641.512.103 88214608 UD17008S 20432346OE 228080-8852 246-25255 S-80449Video/Publications
11040923 19168N 20432346OE 228000-8850 228000-8851 228000-8852 228080-8852 246-25255 254831D 3935200 3957595 6040643.1 641.512.103 88214608 CST40643GS DENDSN966 S-80449 STN8850 STR70311 UD17008SAdd Your Number
