Specifications
Kilowatt | 2.7 kW |
Length (L.1) | 297 mm |
Mount Hole Center - Center (O.1) | 89 mm |
Mount Hole Center - Center (O.2) | 89 mm |
Mount Hole Center - Center (O.3) | 126 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 11 mm |
Mount Hole Diameter (C.3) | 11 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 29 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CATERPILLAR | 216 3.0 | [3034] | 01.1999-12.2004 |
CATERPILLAR | 226 3.0 | [3034] | 01.1999-12.2004 |
CATERPILLAR | 232 3.0 | [3034] | 01.1999-12.2004 |
CATERPILLAR | 236 3.0 | [3034] | 01.1999-12.2004 |
CATERPILLAR | 242 3.0 | [3034] | 01.1999-12.2004 |
CATERPILLAR | 246 3.0 | [3034] | 01.1999-12.2004 |
CATERPILLAR | 248 3.0 | [3034] | |
CATERPILLAR | 252 3.0 | [3034] | 01.1999-12.2004 |
CATERPILLAR | 906 3.0 | [3034] | 01.1998-12.2008 |
CATERPILLAR | Engine | [704-30] | 01.1998-12.2006 |
CATERPILLAR | TC560B 4.4 | 01.2004-12.2006 | |
CATERPILLAR | TH220B 4.4 | [3054E] | 01.2003-12.2009 |
CATERPILLAR | TH330B 4.4 | [3054E] | 01.2003-12.2009 |
CATERPILLAR | TH340B 4.4 | [3054E] | 01.2003-12.2009 |
CATERPILLAR | TH350B 4.4 | [3054E] | 01.2003-12.2009 |
CATERPILLAR | TH360B 4.4 | [3054E] | 01.2003-12.2009 |
CATERPILLAR | TH407 4.4 | [C4.4] | 01.2008-12.2008 |
CATERPILLAR | TH414 4.4 | [C4.4] | 01.2009-12.2017 |
CATERPILLAR | TH417 4.4 | [C4.4] | 01.2009-12.2017 |
CATERPILLAR | TH460B 4.4 | [3054E] | 01.2003-12.2009 |
CATERPILLAR | TH514 4.4 | [C4.4] | 01.2009-12.2017 |
CATERPILLAR | TH560B 4.4 | [3054] | 01.2003-12.2007 |
CATERPILLAR | TH560B 4.4 | [3054E] | 01.2003-12.2009 |
CATERPILLAR | TH580B 4.4 | [3054E] | 01.2003-12.2009 |
CATERPILLAR | TL1255 4.4 | [C4.4TA] | 01.2008-12.2012 |
Reference Information
DS1445 0R9702 EAA-111704 640.521.103 228000-7500 DENDSN2055 STN7501 254491 S6405S 91-29-5490 DSN2055 228080-7500 115323 6040364 DRS0335 20432463BN 5040578 CST40364AS 8826 S-8651 18992R S12DE0378A2 18992N 144-9955 STR70096 336462 1449955 190-25119 246-25163 UD17020SVideo/Publications
0R9702 115323 144-9955 1449955 18992N 18992R 190-25119 20432463BN 228000-7500 228080-7500 246-25163 254491 6040364.0 640.521.103 8826 91-29-5490 CST40364AS DENDSN2055 DRS0335 DS1445 EAA-111704 S-8651 STN7501 STR70096 UD17020S S6405SAdd Your Number
