Specifications
Kilowatt | 7.8 kW |
Length (L.1) | 315 mm |
Mount Hole Center - Center (O.1) | 126 mm |
Mount Hole Center - Center (O.2) | 90 mm |
Mount Hole Center - Center (O.3) | 90 mm |
Mount Hole Diameter (C.1) | 12 mm |
Mount Hole Diameter (C.2) | 12 mm |
Mount Hole Diameter (C.3) | 12 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 48 mm |
Rotation | CW |
Spigot Diameter (A) | 89 mm |
Unit Type | DENSO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
JOHN DEERE | 620G 6.8 | [6068] | 01.2017-12.1018 |
JOHN DEERE | 620GP 6.8 | [6068] | 01.2017-12.1018 |
JOHN DEERE | 622G 6.8 | [6068] | 01.2017-12.1018 |
JOHN DEERE | 622GP 6.8 | [6068] | 01.2018-12.1018 |
JOHN DEERE | 670C 6.8 | [6068] | 01.1996-12.2002 |
JOHN DEERE | 670CH 6.8 | [6068] | 01.1996-12.2002 |
JOHN DEERE | 670D 6.8 | [6068] | 01.2005-12.2009 |
JOHN DEERE | 670G 6.8 | [6068] | 01.2009-12.2018 |
JOHN DEERE | 670GP 6.8 | [6068] | 01.2009-12.2018 |
JOHN DEERE | 672CH 6.8 | [6068] | 01.1996-12.2002 |
JOHN DEERE | 672D 6.8 | [6068] | 01.2005-12.2009 |
JOHN DEERE | 672G 6.8 | [6068] | 01.2009-12.2018 |
JOHN DEERE | 672GP 6.8 | [6068] | 01.2009-12.2018 |
Reference Information
91-29-5832 STN9630 246-30233 20432256OE 228000-9631 631.510.113 RE505465 6040652 228000-9630 CST40652GS TG2280809631 UD17029S 256314D 190-30210 S-80465 STR70451Video/Publications
190-30210 20432256OE 228000-9630 228000-9631 246-30233 256314D 6040652 631.510.113 91-29-5832 CST40652GS RE505465 S-80465 STN9630 STR70451 TG2280809631 UD17029SAdd Your Number
