Specifications
| Kilowatt | 3 kW |
| Length (L.1) | 279 mm |
| Mount Hole Center - Center (O.1) | 90 mm |
| Mount Hole Center - Center (O.2) | 127 mm |
| Mount Hole Center - Center (O.3) | 90 mm |
| Mount Hole Diameter (C.1) | 11 mm |
| Mount Hole Diameter (C.2) | 11 mm |
| Mount Hole Diameter (C.3) | 11 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Oil Sealed | Yes |
| Pinion at Rest (B) | 47 mm |
| Rotation | CW |
| Spigot Diameter (A) | 89 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| DODGE | Ram 2500 5.9 | [ETC] | 01.2001-12.2008 |
| DODGE | Ram 2500 5.9 | [ETC] | 01.2003-12.2003 |
| DODGE | Ram 2500 5.9 | [ETH] | 01.2003-12.2008 |
| DODGE | Ram 2500 6.7 | [ETJ] | 01.2007-12.2009 |
| DODGE | Ram 2500 6.7 | [ETJ] | 01.2007-12.2012 |
| DODGE | Ram 2500 6.7 | [ETJ] | 01.2008-12.2010 |
| DODGE | Ram 2500 6.7 | [ETJ] | 01.2010-12.2010 |
| DODGE | Ram 3500 5.9 | [ETC] | 01.2001-12.2008 |
Reference Information
4982056 19029N 68049020AA UD16535S 68002981AA 61966 LRS04180 428000-3330 91-29-5747N 6040462 190-90107 428000-3331 25-5343 S-80404 246-31101 91-29-5747 115566 05086932AA MAV424620A CST40462AS STN4339 335743 280-0374 LRS4180 STR70477 S6413S 20432264BN 19029R 428000-6110 4934925 DEN428000-6110 830.924.133Video/Publications
115566 190-90107 19029N 19029R 246-31101 25-5343 280-0374 428000-3330 428000-3331 428000-6110 4934925 4982056 68002981AA 68049020AA 830.924.133 91-29-5747 91-29-5747N DEN428000-6110 LRS04180 LRS4180 S-80404 STN4339 STR70477 UD16535S S6413SAdd Your Number
