Information
428000-9260Specifications
Kilowatt | 1.50 kW |
Length (L.1) | 215 mm |
Mount Hole Center - Center (O.1) | 95 mm |
Mount Hole Diameter (C.1) | M10x1.25 mm |
Mount Hole Diameter (C.2) | M10x1.25 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 2 qty |
No./Teeth | 15 qty |
OEM Product | No |
Pinion at Rest (B) | 18 mm |
Product Line | Standard Line |
Product Type | Brand new |
Rotation | CW |
Spigot Diameter (A) | 70 mm |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KIA | Carens 2.0 GDi | [G4NC] | 07.2013- |
KIA | Soul 1.6 GDi | [G4FD] | 02.2014- |
Reference Information
10985N | WAI / TRANSPO |
20432675BN | REAL |
36100-2E301 | HYUNDAI / KIA |
361002E301SJ | HYUNDAI / KIA |
428000-9260 | DENSO |
6040576.0 | SANDO |
91-29-5889 | WILSON |
CST40576AS | CASCO |
DRS0951 | DELCO |
DS2061 | DELCO |
S6422S | AS-PL |
S-80603 | DIXIE |
STN3189 | KRAUF |
STR70507 | WOODAUTO |
UD18551S | AS-PL |
Video/Publications
