Specifications
| Kilowatt | 5 kW |
| Length (L.1) | 447 mm |
| Mount Hole Center - Center (O.1) | 126 mm |
| Mount Hole Center - Center (O.2) | 126 mm |
| Mount Hole Center - Center (O.3) | 126 mm |
| Mount Hole Diameter (C.1) | 13.5 mm |
| Mount Hole Diameter (C.2) | 13.5 mm |
| Mount Hole Diameter (C.3) | 13.5 mm |
| No./Mount holes | 3 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 13 qty |
| Pinion at Rest (B) | 46.5 mm |
| Rotation | CW |
| Spigot Diameter (A) | 92 mm |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| PERKINS | Engine |
Reference Information
428000-9230 UD18932S 3731665Video/Publications
3731665 428000-9230 UD18932SAdd Your Number
