Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
ISKRA / LETRIKA
Price:
NZ$ 334.66 including GST
NZ$ 291.01 excluding GST
or four payments of $83.67
with
Learn More
each
S9200S
1
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
Information
11.130.923Associated Numbers
000050495901Specifications
| Kilowatt | 2 kW |
| Length (L.1) | 232 mm |
| Mount Hole Center - Center (O.1) | 102 mm |
| Mount Hole Diameter (C.1) | 13 mm |
| Mount Hole Diameter (C.2) | 13 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 0 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 40.50 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 82.50 mm |
| Unit Type | ISKRA / LETRIKA |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| HATZ | Engine | [1D81C] | 01.2007- |
| HATZ | Engine | [1D90] | 01.2007- |
Reference Information
| 000050495901 | HATZ |
| 01721000 | KHD |
| 05710924 | BOMAG |
| 05726001 | BOMAG |
| 05728551 | BOMAG |
| 05821275 | BOMAG |
| 101340 | KUHNER |
| 101340M | KUHNER |
| 11.130.923 | ISKRA / LETRIKA |
| 11.131.528 | ISKRA / LETRIKA |
| 113982 | CARGO |
| 116458 | CARGO |
| 1721000 | KHD |
| 182-30125 | ROBERT'S |
| 19083005 | DELCO |
| 20419811OE | REAL |
| 25-4043 | ELSTOCK |
| 273-20102 | DIXIE |
| 30231N | WAI / TRANSPO |
| 503534210891 | HATZ |
| 50495900 | HATZ |
| 50495901 | HATZ |
| 504959010733 | HATZ |
| 55169.7 | BOBCAT |
| 55170 | BOBCAT |
| 5726001 | BOMAG |
| 5726003R | BOMAG |
| 6021118.1 | SANDO |
| 72736060 | MAHLE |
| 730.503.092 | PSH |
| 8289 | CEVAM |
| 91-23-6526 | WILSON |
| 98417134 | FIAT |
| ANM12486X | ANDEL |
| AZE2663 | ISKRA / LETRIKA |
| CST21118GS | CASCO |
| DRS0266 | DELCO |
| DS1376 | DELCO |
| F032113982 | CARGO |
| F032116458 | CARGO |
| IS1150 | ISKRA / LETRIKA |
| LRS02371 | LUCAS |
| LRS2371 | LUCAS |
| MAHMS432 | WOODAUTO |
| MAV122450 | SIOM |
| MAV123140 | SIOM |
| MS432 | MAHLE |
| S135.381 | PSH |
| S144.343 | PSH |
| S-6251 | DIXIE |
| S9200S | AS-PL |
| STI3982 | KRAUF |
| STI9982 | KRAUF |
| STR60634 | WOODAUTO |
| STR7912 | ELECTROLOG |
| UD11310S | AS-PL |
