Specifications
Kilowatt | 1.4 kW |
Length (L.1) | 226 mm |
Mount Hole Center - Center (O.1) | 132 mm |
Mount Hole Diameter (C.1) | 11 mm |
Mount Hole Diameter (C.2) | 10 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 10 qty |
Pinion at Rest (B) | 4 mm |
Rotation | CW |
Spigot Diameter (A) | 104 mm |
Unit Type | FORD |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
FORD | Explorer 4.0 | 01.1991-12.2003 | |
FORD | Ranger 4.0 | 01.1990-12.2011 | |
MAZDA | B4000 4.0 | 01.1994-12.2009 | |
MAZDA | Navajo 4.0 | 01.1991-12.1994 |
Reference Information
UD20610S 3240R STF0093 F87U-11000-BA 3240N 880.518.102 91-02-5920N STR8009 F87Z-11002-BA S-2057 STR82423Video/Publications
3240N 3240R 880.518.102 91-02-5920N F87U-11000-BA F87Z-11002-BA S-2057 STF0093 STR82423 UD20610SAdd Your Number
