Specifications
Kilowatt | 5.5 kW |
Length (L.1) | 320 mm |
Mount Hole Center - Center (O.1) | 111 mm |
Mount Hole Center - Center (O.2) | 111 mm |
Mount Hole Center - Center (O.3) | 135 mm |
Mount Hole Diameter (C.1) | 14 mm |
Mount Hole Diameter (C.2) | 14 mm |
Mount Hole Diameter (C.3) | 14 mm |
No./Mount holes | 3 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 11 qty |
Pinion at Rest (B) | 40 mm |
Rotation | CW |
Spigot Diameter (A) | 105 mm |
Unit Type | NIKKO |
Voltage | 24 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
KOMATSU | Various Models |
Reference Information
UD17027S 0-21000-4132 18074 STR8195Video/Publications
0-21000-4132 18074 STR8195 UD17027SAdd Your Number
