Specifications
Kilowatt | 1.7 kW |
Length (L.1) | 230 mm |
Mount Hole Center - Center (O.1) | 108 mm |
Mount Hole Diameter (C.1) | 10.5 mm |
Mount Hole Diameter (C.2) | 10.5 mm |
No./Mount holes | 2 qty |
No./Mount holes with thread | 0 qty |
No./Teeth | 17 qty |
Pinion at Rest (B) | 23 mm |
Rotation | CW |
Spigot Diameter (A) | 68 mm |
Unit Type | GM |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
OPEL | Insignia 1.5 | [B15SFT] | 01.2017- |
OPEL | Insignia 1.5 | [D15SFT] | 01.2017- |
OPEL | Insignia 1.5 Country Tourer | [B15SFT] | 01.2017- |
OPEL | Insignia 1.5 Country Tourer | [D15SFT] | 01.2017- |
OPEL | Insignia 1.5 Sports Tourer | [B15SFT] | 01.2017- |
OPEL | Insignia 1.5 Sports Tourer | [D15SFT] | 01.2017- |
OPEL | Mokka 1.4 | [B14XFT] | 01.2016- |
VAUXHALL | Mokka 1.4 | [B14XFT] | 01.2016- |
Reference Information
95523340 95526427 130-10159 UD18601S LRS04182 695085118 12680615 12673600 S-80705 25-5345 LRS4182 DRS1387 S9415SVideo/Publications
12673600 12680615 130-10159 25-5345 695085118 95523340 95526427 DRS1387 LRS04182 LRS4182 S-80705 UD18601SAdd Your Number
