Specifications
Inside Diameter (I.D.1) | 17 mm |
Length (L.1) | 70 mm |
Length (L.2) | 21.5 mm |
No./Splines | 12 qty |
No./Teeth | 13 qty |
Outside Diameter (O.D.1) | 60 mm |
Outside Diameter (O.D.2) | 45.5 mm |
Rotation | CW |
Type | Drive |
Unit Type | LUCAS/MARELLI |
Reference Information
SDV3177 CDR25101 SD4101P ZN0541 25-44-96 1.01.0541.0 132852 UD17695SD 225216 TNB167 DRV4185 SDL5852 541 1567 85541459 1013267 54268140010 85541459010 SDR25101 54268140Video/Publications
CDR25101 SD4101P ZN0541 132852 UD17695SD 27501 27567 0541 63227501 63227567 1013267 085541459010 054268140010 27531A SDV3177 27501A 27501B 27531D 25-44-96 1.01.0541.0 27501E 27531B 225216 27577 TNB167 SDL5852 1567 27531 SDR25101Add Your Number
