Associated Numbers
Accurate 3-649, 4-649
Ace Electric 4-916
Bosch 1-198-7BE-009, 1-198-7BE-023, 1-987-BE0-009, 1-987-BE0-032
Daihatsu 28011-15010-000, 28011-41020-000
DENSO 028300-0660, 028300-085, 028300-0900, 028300-0901, 028300-0910, 028300-0911, 028300-1950, 028300-1951, 028300-3350, 028300-3351, 028300-800
Facet 5-0140
IAT 01513, 01567, 615-648
IPM (Wabash) 2K-5001
Italacciai SD183, SD359
Kubota 14278-63041
LUCAS TMJ402
Lucas Indiel 223199
PIC 6190-2367
Toyota 28011-15010, 28011-41020, 28011-41021, 28011-5010, 28011-60040, 28011-60041
28100-15031-000,
DENSO 028000-043, 028000-0430, 028000-101, 028000-1010, 028000-1013, 028000-137, 028000-1370, 028000-1371, 028000-1372, 028000-162, 028000-1620, 028000-1622, 028000-1623, 028000-173, 028000-1730, 028000-174, 028000-1740, 028000-194, 028000-1940, 028000-1941, 028000-197, 028000-1970, 028000-1971, 028000-1972, 028000-1973, 028000-1974, 028000-1975, 028000-1976, 028000-200, 028000-2000, 028000-2001, 028000-225, 028000-2250, 028000-226, 028000-2260, 028000-2261, 028000-2262, 028000-2263, 028000-233, 028000-2330, 028000-236, 028000-2360, 028000-2361, 028000-2362, 028000-2363, 028000-2364, 028000-257, 028000-2570, 028000-2571, 028000-2572, 028000-266, 028000-2660, 028000-2661, 028000-2662, 028000-2663, 028000-2664, 028000-2665, 028000-268, 028000-2680, 028000-2681, 028000-2682, 028000-305, 028000-3050, 028000-3051, 028000-3052, 028000-309, 028000-3090, 028000-310, 028000-3100, 028000-360, 028000-3600, 028000-3601, 028000-3602, 028000-3603, 028000-3604, 028000-370, 028000-3700, 028000-371, 028000-3710, 028000-3711, 028000-382, 028000-3820, 028000-3821, 028000-3822, 028000-3823, 028000-3824, 028000-3825, 028000-3827, 028000-384, 028000-3840, 028000-3841, 028000-392, 028000-3920, 028000-3921, 028000-401, 028000-4010, 028000-4011, 028000-427, 028000-4270, 028000-4271, 028000-433, 028000-4330, 028000-4331, 028000-434, 028000-4340, 028000-4341, 028000-4342, 028000-4343, 028000-4440, 028000-448, 028000-4480, 028000-449, 028000-4490, 028000-4491, 028000-458, 028000-4580, 028000-461, 028000-4611, 028000-464, 028000-4640, 028000-481, 028000-4810, 028000-4811, 028000-4812, 028000-498, 028000-4980, 028000-533, 028000-5330, 028000-5331, 028000-5332, 028000-5334, 028000-5335, 028000-5336, 028000-543, 028000-5430, 028000-557, 028000-5570, 028000-6210, 028000-6213, 028000-638, 028000-6380, 028000-6381, 028000-6382, 028000-6383, 028000-6384, 028000-6385, 028000-639, 028000-6390, 028000-6391, 028000-6393, 028000-6394, 028000-6396, 028000-642, 028000-6420, 028000-6421, 028000-6422, 028000-643, 028000-6430, 028000-646, 028000-6460, 028000-6461, 028000-6462, 028000-6463, 028000-649, 028000-6490, 028000-6491, 028000-6492, 028000-6493, 028000-6494, 028000-660, 028000-6600, 028000-672, 028000-6720, 028000-6721, 028000-680, 028000-6800, 028000-6802, 028000-681, 028000-6810, 028000-6811, 028000-6812, 028000-6813, 028000-682, 028000-6820, 028000-6821, 028000-6822, 028000-6823, 028000-709, 028000-7090, 028000-7091, 028000-7092, 028000-7093, 028000-710, 028000-7100, 028000-7101, 028000-7102, 028000-713, 028000-7130, 028000-7131, 028000-7132, 028000-7133, 028000-733, 028000-7330, 028000-7331, 028000-7332, 028000-746, 028000-7460, 028000-7461, 028000-7462, 028000-747, 028000-7470, 028000-7471, 028000-7472, 028000-752, 028000-7520, 028000-7521, 028000-778, 028000-7780, 028000-7781, 028000-798, 028000-7980, 028000-7981, 028000-801, 028000-8010, 028000-816, 028000-8160, 028000-847, 028000-8470, 028000-869, 028000-8690, 028000-911, 028000-9110, 028000-9111, 028000-9112, 028000-9113, 028000-957, 028000-9570, 028000-968, 028000-9680, 128000-029, 128000-0290, 128000-067, 128000-0670, 128000-161, 128000-1610, 128000-205, 128000-2050, 128000-523, 128000-5230, 128000-813, 128000-8130, 128000-954, 128000-9540,
DENSO Auto Parts 280-0107, 280-0108, 280-0201, 280-0204, 280-0213, 280-7007, 280-7009, 280-7010, 280-7014,
Denso Reman 9702809-713, 9702809-746, 9702809-747, 9702809-778, 9712809-029, 9712809-954,
Dynamic DS16238,
Ford SBA18508-6280, SBA18508-6370, SBA18508-6540,
Freightliner ABPN83030153,
Hella 8EA737134-001,
Hitachi Automotive S114-211, S114-227, S114-245,
Honda 06312-PE0-003RM, 31200-637-600, 31200-657-004, 31200-657-005, 31200-657-015, 31200-657-016, 31200-657-025, 31200-PA0-006, 31200-PA0-016, 31200-PA5-9112, 31200-PA5-9130, 31200-PC0-004, 31200-PC1-004, 31200-PE0-003, 31200-PE0-013, 31200-PE0-013RM, 31200-PE0-901, 31200-PE0-9020, 31200-PE5-L01, 31200-PM5-L01, 31200-PM5-L01RM, 31200-PM5-L03, DFDE6, DFKEE, DFLEA,
Hyster 3004571, 3049481,
Ishikawajima 18508-6280, 18508-6370, 18508-6540,
Kubota 12475-63011, 14278-63010, 14278-63011, 14278-63012, 14278-63013, 14278-63014, 14601-63011, 14601-63012, 15231-63012, 15231-63013, 15231-63014, 15231-63015, 15231-63016, 15271-63C13, 16097-61361, 19293-63011, E7199-63010,
Lester 16217, 16218, 16218, 16218, 16218, 16218, 16220, 16222, 16223, 16223, 16224, 16224, 16230, 16230, 16230, 16231, 16238, 16251, 16261, 16499, 16499, 16586, 16586, 16589, 16735, 16766, 16766, 16766, 16832, 16832, 16843, 16911, 17278, 17278, 17350, 17354, 17354, 17354, 17364, 18183, 30049, 30511, 30511, 30600,
Lester Old 16214, 16219, 16226, 16234, 16235, 16236, 16240, 16243, 16249, 16263, 16264, 16596, 16624, 16625, 16704, 16734, 16764, 16842, 16899, 16907, 16912, 16920, 17053,
Lucas (Europe) LRS00226, LRS226,
Lucas Reman S1147, S9018, S9018, S9025, S9025, S9027, S9027, S9027, S9027, S9033, S9043, S9043, S9046, S9054, S9079C, S9301C, S9301C, S9307C, S9702, S9707, S9707, S9707,
NAPA 244-4477, 244-4519, 244-4519, 244-4519, 244-4648, 244-4773, 244-4773, 244-4891, 244-6916, 44-4477, 44-4477, 44-4477, 44-4519, 44-4519, 44-4645, 44-4648, 44-4773, 44-4773, 44-4780, 44-4780, 44-4780, 44-4833, 44-4864, 44-4891, 44-4891, 44-4895, 44-6030, 44-6048, 44-6052, 44-6053, 44-6054, 44-6054, 44-6108, 44-6507,
New Holland Agriculture SBA18508-6370, SBA18508-6540,
Onan 15231-63014,
PIC 104-137A, 190-005, 190-005A, 190-007, 190-009, 190-009A, 190-013E, 190-016, 190-016A, 190-016B, 190-018, 190-022, 190-022B, 190-024, 190-024A, 190-025, 190-026, 190-027, 190-033, 190-034, 190-091, 190-092, 190-092A, 190-094, 190-094A, 190-094C, 190-103, 190-104A, 190-108, 190-113, 190-114, 190-114A, 190-114B, 190-114C, 190-114D, 190-117, 190-117A, 190-198, 190-230, 190-230A, 190-339, 190-349, 190-353, 190-518, 911-781, 911-787,
Remy 16218, 16218, 16218, 16218, 16220, 16224, 16224, 16230, 16230, 16230, 16236, 16236, 16251, 16499, 16589, 16719, 16766, 16766, 16832, 16911, 16915, 69022, 69022, 69022,
Remy Power Products RS41277, RS41277, RS41277, RS41300,
Toyota 10015-130, 28100-031021, 28100-13020, 28100-13020K, 28100-13030, 28100-15010, 28100-15011, 28100-15011-84, 28100-15031, 28100-15060, 28100-15110, 28100-15111, 28100-15160, 28100-15170, 28100-23010, 28100-23011, 28100-23800, 28100-23800-71, 28100-25030, 28100-25031, 28100-25032, 28100-26031, 28100-26142, 28100-26160, 28100-27020, 28100-31020, 28100-31021, 28100-31030, 28100-33011, 28100-33020, 28100-33020, 28100-34010, 28100-34070, 28100-34079, 28100-36020, 28100-36040, 28100-36050, 28100-36051, 28100-36060, 28100-37010, 28100-37011, 28100-40010, 28100-40011, 28100-40012, 28100-40013, 28100-40014, 28100-40015, 28100-40040, 28100-40041, 28100-40050, 28100-40060, 28100-40061, 28100-41010, 28100-41011, 28100-41012, 28100-41013, 28100-41020, 28100-41021, 28100-41050, 28100-42010, 28100-42011, 28100-42020, 28100-42021, 28100-42030, 28100-45020, 28100-45021, 28100-45022, 28100-45023, 28100-45024, 28100-45030, 28100-45031, 28100-45032, 28100-45033, 28100-46040, 28100-48011, 28100-60010, 28100-60040, 28100-60041, 28100-60042, 28100-60060, 28100-60061, 28100-60062, 28100-76011-71,
Unipoint STR-3565, STR-3570, STR-3570, STR-3572, STR-3572, STR-3573, STR-3573, STR-3574, STR-3574, STR-3574, STR-3574, STR-3574, STR-6159,
Universal Marine 299512, 301295,
Valeo Short VS228,
Specifications
| Inside Diameter (I.D.1) | 12.50 mm |
| Length (L.1) | 82 mm |
| Length (L.2) | 37.30 mm |
| No./Splines | 10 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Outside Diameter (O.D.1) | 46.50 mm |
| Outside Diameter (O.D.2) | 29.20 mm |
| Product Line | Premium Line |
| Product Type | Brand new |
| Rotation | CW |
| Type | Drive |
| Unit Type | DENSO |
Reference Information
| 0140 | ZEN |
| 028300-0660 | DENSO |
| 028300-0901 | DENSO |
| 028300-0911 | DENSO |
| 028300-1951 | DENSO |
| 028300-3350 | DENSO |
| 1.01.0140.0 | ZEN |
| 1987BE0023 | BOSCH |
| 225066 | ERA |
| 28011-15010 | TOYOTA |
| 28011-41020 | TOYOTA |
| 28011-41021 | TOYOTA |
| 28011-60040 | TOYOTA |
| 28011-60041 | TOYOTA |
| DRV6001 | ELECTROLOG |
| SD6002P | AS-PL |
| UD17608SD | AS-PL |
| ZN0140 | ZEN |
Video/Publications
