Specifications
B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 13 mm |
L.B+ | 25.5 mm |
Length (L.1) | 116.5 mm |
Outside Diameter (O.D.1) | 58 mm |
Outside Diameter (O.D.2) | 59 mm |
Type | Solenoid |
Unit Type | FORD |
Voltage | 12 V |
Reference Information
SOL8500 ZM816 SS9183P 227801 L1033Video/Publications
F7HZ11002FA F7HZ11002EA F7HT11001EA 227801 L1033 F7HZ11002EARM F7HZ11002FARM ZM816 F7HT11001FA SA847RM SA846RM SA846 SS9183P SA847Add Your Number
