Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 12 mm |
L.B+ | 16 mm |
Length (L.1) | 93 mm |
Outside Diameter (O.D.1) | 50 mm |
Outside Diameter (O.D.2) | 51 mm |
Type | Solenoid |
Unit Type | PRESTOLITE |
Voltage | 12 V |
Reference Information
227804 88DR-11001-A ZM821 SS9184PVideo/Publications
35258000 227804 88DR-11001-A ZM821 SS9184PAdd Your Number
