Specifications
B+ Stud Diameter & Thread Pitch (B+) | M8x1.25 mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M8x1.25 mm |
Coil Bolt Length | 15 mm |
L.B+ | 16.5 mm |
Length (L.1) | 77 mm |
Outside Diameter (O.D.1) | 51.5 mm |
Outside Diameter (O.D.2) | 44.5 mm |
Type | Solenoid |
Unit Type | UNIVERSAL |
Voltage | 12 V |
Reference Information
LFB479Q SS9210P 3708100A ZM1992Video/Publications
LFB479Q 8179001 SS9210P 3708100A ZM1992Add Your Number
