Specifications
B+ Stud Diameter & Thread Pitch (B+) | M10x1.5 mm |
Coil Bolt Diameter & Thread Pitch (Coil Bolt) | M10x1.5 mm |
Coil Bolt Length | 24.5 mm |
Inside Diameter (I.D.1) | 30 mm |
L.B+ | 20 mm |
Length (L.1) | 85.7 mm |
Outside Diameter (O.D.1) | 61 mm |
Outside Diameter (O.D.2) | 54 mm |
Type | Solenoid |
Unit Type | ISKRA / LETRIKA |
Voltage | 12 V |
Reference Information
SOL79242 72739463 MSX MSX1100 MAHMSX1100KIT UD46377SS 1100KIT 16.915.753Video/Publications
AZE4238 11131575 11131574 16.915.753 S9199(LETRIKA) 11132153 AZF4147 AZF4148 72739463 MSX MAHMSX1100KIT UD46377SS 1100KITAdd Your Number
