Brand new AS-PL Alternator
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 499.69 including GST
NZ$ 434.51 excluding GST
or four payments of $124.92
with
Learn More
each
A0815S
No stock in NZ currently
This item can be backordered, A B/O fee is applied at checkout - Aprox 7-14 day delay on delivery. **B/O products are not returnable**
- Information
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- Related Items
Information
0124525097Specifications
| Amp | 155 A |
| Bottom Mounting Foot Width (B) | 14 mm |
| Diameter (D.1) | 8 mm |
| Diameter (D.2) | 8 mm |
| Diameter (D.3) | M8x1.25 mm |
| Diameter (D.4) | M8x1.25 mm |
| Length (L.1) | 195 mm |
| Mount Inside Length or Pad Mount C-C (C) | 57 mm |
| OEM Product | No |
| Plug Code | PL_2200 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley Grooves | 6 qty |
| Pulley Outside Diameter (O.D.1) | 57 mm |
| Pulley to Mount Distance (A) | 40.50 mm |
| Pulley Type | Clutch |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| OPEL | Signum 2.8 V6 Turbo | [Z28NEL] | 09.2005-12.2008 |
| OPEL | Signum 2.8 V6 Turbo | [Z28NET] | 01.2006-12.2008 |
| OPEL | Vectra C 2.8 V6 Turbo | [Z28NEL] | 08.2005-10.2006 |
| OPEL | Vectra C 2.8 V6 Turbo | [Z28NEL] | 08.2005-10.2008 |
| OPEL | Vectra C 2.8 V6 Turbo | [Z28NET] | 07.2006-08.2008 |
| OPEL | Vectra C 2.8 V6 Turbo | [Z28NET] | 08.2005-08.2008 |
| OPEL | Vectra C 2.8 V6 Turbo | [Z28NET] | 08.2005-09.2006 |
| OPEL | Vectra C 2.8 V6 Turbo | [Z28NET] | 08.2005-09.2008 |
| OPEL | Vectra C 2.8 V6 Turbo GTS | [Z28NEL] | 08.2005-08.2008 |
| OPEL | Vectra C 2.8 V6 Turbo GTS | [Z28NET] | 08.2005-08.2008 |
| OPEL | Vectra C 2.8 V6 Turbo GTS | [Z28NET] | 08.2005-09.2008 |
| OPEL | Vectra C 2.8 V6 Turbo GTS | [Z28NET] | 08.2006-08.2008 |
| OPEL | Vectra C 2.8 V6 Turbo OPC | [Z28NET] | 09.2006-08.2008 |
| SAAB | 9-3 2.8 Turbo V6 | [B284L] | 12.2007-02.2015 |
| SAAB | 9-3 2.8 Turbo V6 | [B284R] | 02.2009-02.2015 |
| SAAB | 9-3 2.8 Turbo V6 | [LP9] | 02.2006-02.2015 |
| SAAB | 9-3 2.8 Turbo V6 | [LP9] | 03.2005-02.2015 |
| SAAB | 9-3 2.8 Turbo V6 XWD | [B284R] | 05.2008-12.2011 |
Reference Information
| 0124525097 | BOSCH |
| 11187R | WAI / TRANSPO |
| 1203243 | OPEL |
| 1279963 | STEYR |
| 12799630 | OPEL |
| 135.537.155.210 | PSH |
| 1986A01157 | BOSCH |
| 20101753BN | REAL |
| 20101753OE | REAL |
| 20101753RC | REAL |
| 2010357.0 | SANDO |
| 2010357.1 | SANDO |
| 2010357.2 | SANDO |
| 28-6786 | ELSTOCK |
| 4380 | CEVAM |
| 554005RIB | KUHNER |
| 57258 | EAI |
| 6204250 | OPEL |
| 90-15-6518 | WILSON |
| 93187415 | OPEL |
| 93189253 | OPEL |
| 98648297 | OPEL |
| A-6545 | DIXIE |
| AEK3646 | AUTOELECTRO |
| ALB2597 | KRAUF |
| ALT123570 | SIOM |
| ALT1404 | ELECTROLOG |
| ALTE294 | 3EFFE |
| BOS0124525097 | WOODAUTO |
| CAL10357AS | CASCO |
| CAL10357GS | CASCO |
| CAL10357RS | CASCO |
| CGB-86786 | AINDE |
| DB9407 | DELCO |
| DRB8297 | DELCO |
| LRA03646 | LUCAS |
| LRA3646 | LUCAS |
| PRAE294 | 3EFFE |
| STX110166 | STARDAX |
| STX110166R | STARDAX |
| UD19415A | AS-PL |
