Specifications
Amp | 80 A |
Bottom Mounting Foot Width (B) | 13 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | 10.5 mm |
Grooves | 1 qty |
Groove Width (W.1) | 16 mm |
Length (L.1) | 245 mm |
Mount Inside Length or Pad Mount C-C (C) | 82 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 50 mm |
Outside Diameter (O.D.2) | 82 mm |
Plug Code | PL_4510 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 49 mm |
Pulley Type | SOLID |
Unit Type | HITACHI |
Vacuum Pump | Yes |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
ISUZU | Panther 2.5 Grand Touring |
Reference Information
LR160-506 8976956020 ALH3468 UD19305AVideo/Publications
8976956020 LR160-506 UD19305A ALH3468Add Your Number
