Information
FG15S026Specifications
Amp | 150 A |
Diameter (D.1) | 10.50 mm |
Diameter (D.2) | 12 mm |
Diameter (D.3) | 11 mm |
Length (L.1) | 187 mm |
Mount Inside Length or Pad Mount C-C (C) | 48 mm |
OEM Product | No |
Pad mount thickness (E.1) | 50 mm |
Pad mount thickness (E.2) | 20 mm |
Pad mount thickness (E.3) | 50 mm |
Plug Code | PL_2201 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 6 qty |
Pulley Outside Diameter (O.D.1) | 56 mm |
Pulley to Mount Distance (A) | 27 mm |
Pulley Type | Clutch |
Unit Type | VALEO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
CHEVROLET | Camaro 3.6 V6 | 01.2010-12.2012 | |
CHEVROLET | Colorado 3.6 V6 | 01.2015-12.2016 | |
GMC | Canyon 3.6 V6 | 01.2015-12.2016 |
Reference Information
11485N | WAI / TRANSPO |
13502988 | DELCO |
13588313 | DELCO |
2605329A | VALEO |
555237RI | KUHNER |
90-22-5631 | WILSON |
A3562S | AS-PL |
A-9553 | DIXIE |
ALT01193 | ELECTROLOG |
ALV2416 | KRAUF |
FG15S026 | VALEO |
FG15S081 | VALEO |
UD21118A | AS-PL |
Video/Publications
A3562SRelated Items
