Specifications
| Amp | 130 A |
| Diameter (D.1) | 11 mm |
| Diameter (D.2) | 10.5 mm |
| Diameter (D.3) | 13.5 mm |
| Grooves | 8 qty |
| Length (L.1) | 192 mm |
| Mount Inside Length or Pad Mount C-C (C) | 74 mm |
| OEM Product | No |
| Outside Diameter (O.D.1) | 71 mm |
| Pad mount thickness (E.1) | 55 mm |
| Pad mount thickness (E.2) | 55 mm |
| Pad mount thickness (E.3) | 55 mm |
| Plug Code | PL_3402 |
| Product Line | Standard Line |
| Product Type | Brand new |
| Pulley to Mount Distance (A) | 42 mm |
| Pulley Type | SOLID |
| Unit Type | DENSO |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | F 450 6.4 | 01.2008-12.2010 | |
| FORD | F 550 6.4 | 01.2008-12.2010 |
Reference Information
7C3Z10V346BRM 0AL7668X 11291N CAL40506AS A-80398 7C3Z10346A UD15375A AL7668X 7C3T-10300-FB 554556RI 12922 2040506 20132605BN 104210-5432 ALN5430 7C3Z-10346-A 7C3T-FB 90-29-5696Video/Publications
104210-5432 11291N 12922 554556RI 7C3T-10300-FB 7C3T-FB 7C3Z-10346-A 7C3Z10346A 7C3Z10V346BRM 90-29-5696 A-80398 AL7668X ALN5430 UD15375AAdd Your Number
