Specifications
Amp | 90 A |
Bottom Mounting Foot Width (B) | 57 mm |
Diameter (D.1) | M8x1.25 mm |
Diameter (D.2) | 10.5 mm |
Grooves | 4 qty |
Length (L.1) | 185 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 55 mm |
Plug Code | PL_3314 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 90 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
TOYOTA | MR2 2.0 | [3S-GTE] | 12.1989-07.1999 |
TOYOTA | MR2 2.0 16V | [3S-GE] | 12.1989-09.1999 |
TOYOTA | MR2 2.0 Turbo | [3S-GTE] | 12.1989-07.1999 |
Reference Information
401371RI 101211-7060 101211-7160 2040334 JA1371IR ALTS174 LRA2004 A-8417 DA1126 195.586.090.785 ALTS174RR EAA-221831 CAL40334AS 13502 UD21082A 20132433BN DRA0016 ALT423340A LRA02004 A6661S 27060-74500 195.586.090.050 ALN2433 27060-74440 28-3910 ALT423340 90-29-5267Video/Publications
UD21082A ALTS174 ALTS174RR CAL40334AS DRA0016 DA1126 13502 A-8417 EAA-221831 28-3910 JA1371IR ALN2433 401371RI LRA02004 LRA2004 195.586.090.050 195.586.090.785 20132433BN 2040334.0 ALT423340 ALT423340A 90-29-5267 101211-7060 101211-7160 27060-74440 27060-74500Add Your Number
