Information
104211-4341Associated Numbers
1042114340
Denso
12061212
EuroTec
125903135
PSH
21238N
WAI
2221761352
DRI
288507
Elstock
311005PAA01
Honda
311005PAA01RM
Honda
40699
CEVAM
A146806
Short code
A162027
Short code
A162742
Short code
A6664
AS-PL
A6664S
AS-PL
AEK4398
Auto Electro
AL04271
TMI
ALN3553
Krauf
CSP71
Honda
LRA04398
Lucas
RNL1042114340
RNL
Specifications
Amp | 135 A |
Bottom Mounting Foot Width (B) | 25 mm |
Diameter (D.1) | 8.50 mm |
Diameter (D.2) | 8.50 mm |
Diameter (D.3) | M8x1.25 mm |
Diameter (D.4) | M8x1.25 mm |
Length (L.1) | 185 mm |
Mount Inside Length or Pad Mount C-C (C) | 36.50 mm |
OEM Product | No |
Plug Code | PL_1000 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley Grooves | 7 qty |
Pulley Outside Diameter (O.D.1) | 57.50 mm |
Pulley to Mount Distance (A) | 39.50 mm |
Pulley Type | Clutch |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
HONDA | Civic 1.5 VTEC | [L15B7] | 02.2017- |
HONDA | Civic 1.5 VTEC | [L15B7] | 08.2016- |
HONDA | Civic 1.5 VTEC | [L15BB] | 08.2016- |
HONDA | CR-V 1.5 AWD | [L15BE] | 12.2016- |
HONDA | CR-V 1.5 AWD | [L15BG] | 12.2016- |
HONDA | CR-V 1.5 AWD | [L15BH] | 12.2016- |
HONDA | CR-V 1.5 AWD | [L15BY] | 12.2016- |
HONDA | CR-V 1.5 VTEC | [L15BY] | 08.2017- |
HONDA | CR-V 1.5 VTEC AWD | [L15BY] | 08.2017- |
HONDA | HR-V 1.5 i-VTEC | [L15BY] | 04.2019- |
Reference Information
10370 | DIXIE |
104211-4340 | DENSO |
104211-4341 | DENSO |
28-8507 | ELSTOCK |
31100-5PA-A01 | HONDA |
31100-5PA-A01RM | HONDA |
40699 | CEVAM |
A-80809 | DIXIE |
AEK4398 | AUTOELECTRO |
ALN3553 | KRAUF |
CSP71 | HONDA |
LRA04398 | LUCAS |
LRA4398 | LUCAS |
UD103023A | AS-PL |
UD19341A | AS-PL |
UD21009A | AS-PL |
