Specifications
Amp | 180 A |
Bottom Mounting Foot Width (B) | 28 mm |
Diameter (D.1) | 11 mm |
Diameter (D.2) | 10.5 mm |
Diameter (D.3) | M10x1.5 mm |
Grooves | 6 qty |
Length (L.1) | 201 mm |
Mount Inside Length or Pad Mount C-C (C) | 75.5 mm |
OEM Product | No |
Outside Diameter (O.D.1) | 49 mm |
Plug Code | PL_2306 |
Product Line | Standard Line |
Product Type | Brand new |
Pulley to Mount Distance (A) | 80 mm |
Pulley Type | SOLID |
Unit Type | DENSO |
Voltage | 12 V |
Vehicle Applications
Make | Model | Type | Year |
---|---|---|---|
BMW | 114 d 1.5 | (F20)[B37D15A] | 07.2015-06.2019 |
BMW | 114 d 1.5 | (F21)[B37D15A] | 06.2015- |
BMW | 116 d 1.5 | (F20)[B37D15A] | 03.2015-06.2019 |
BMW | 116 d 1.5 | (F21)[B37D15A] | 03.2015- |
Reference Information
UD19345A 40086 8626086-3 CAL40A27AS 215.924.180.260 12318626086-3 28-7845 2013272ABN 12090980 CGB-87845 ALN2190 2040A27.0 555173RID 12318626089 104210-6731 A6673S LRA4236 8626086 8626089 104210-6730 DRA1895 LRA04236 12318626086 AEG1409 57739Video/Publications
104210-6730 104210-6731 12318626086 12318626089 DRA1895 LRA04236 UD19345A AEG1409 555173RID CAL40A27AS 40086 57739 28-7845 12090980 LRA4236 2013272ABN 2040A27.0 215.924.180.260 ALN2190 CGB-87845Add Your Number
