Brand new AS-PL Starter motor
STANDARD LINE
AS-PL
BOSCH
Price:
NZ$ 234.57 including GST
NZ$ 203.97 excluding GST
or four payments of $58.64
with
Learn More
each
S0533.
S0877S
3
- Information
- Associated Numbers
- Specifications
- Vehicle Applications
- Reference Information
- Video/Publications
- < Critical Notes >
Information
0001108402Associated Numbers
70-1027-1 SNB021 BXS0122 0001108402 Bosch show 0001108472 0986020860 ruil 0986020867 11020860 EuroTec 114315 Cargo 120428 PIC 12090528 12291 EAI 1374049 Ford 17979 Lester 220412 Messmer 254003 Elstock 338041092 DRI 36050273 Volvo 3M5T11000EA 3M5TEA 42020860 Herth Buss 458829 Valeo 4846SP Spidan 8020860F Friesen 810522093 PSH 8602924 8622742 8EA011611401 HC 8EA738258451 91157224 Wilson 920860 944280208600 Magneti Marelli A20860 ATL CS1398 DRT0860 Remy HCS1398 LRS02331 Lucas MRS20860 OSM11802 Optimum SR0814X (USA) STR1499sa Electrolog ARROWHEAD SBO0152 BOSCH 0-001-108-402 0-986-020-860 2086 FORD1374049 3M5T-11000-EA 3M5T-EA J N ELECTRICAL PRODUCTS 410-24256 LESTER LUCAS ELECTRIC LRS2331 VOLVO 8602924-0 S0533Specifications
Bolt down exciter terminal
| Kilowatt | 1.40 kW |
| Length (L.1) | 215 mm |
| Mount Hole Center - Center (O.1) | 105 mm |
| Mount Hole Diameter (C.1) | M10x1.5 mm |
| Mount Hole Diameter (C.2) | M10x1.5 mm |
| No./Mount holes | 2 qty |
| No./Mount holes with thread | 2 qty |
| No./Teeth | 9 qty |
| OEM Product | No |
| Pinion at Rest (B) | 0 mm |
| Product Line | Standard Line |
| Product Type | Brand new |
| Rotation | CW |
| Spigot Diameter (A) | 76 mm |
| Unit Type | BOSCH |
| Voltage | 12 V |
Vehicle Applications
| Make | Model | Type | Year |
|---|---|---|---|
| FORD | Focus 2.5 RS | [JZDA] | 01.2009-12.2011 |
| FORD | Focus 2.5 RS 500 | [JZDA] | 01.2010-12.2011 |
| FORD | Focus 2.5 ST | [HYDA] | 01.2005- |
| VOLVO | C70 2.4 | [B5244S4] | 01.2006-12.2006 |
| VOLVO | C70 2.4 | [B5244S5] | 01.2006-12.2006 |
| VOLVO | C70 2.5 T5 | [B5254T3] | 01.2006-12.2007 |
| VOLVO | C70 2.5 T5 | [B5254T7] | 01.2007-12.2009 |
| VOLVO | S40 2.4 | [B5244S4] | 01.2004- |
| VOLVO | S40 2.4 | [B5244S5] | 01.2004- |
| VOLVO | S40 2.5 T5 | [B5254T3] | 01.2003-12.2006 |
| VOLVO | S40 2.5 T5 | [B5254T7] | 01.2003-12.2006 |
| VOLVO | S40 2.5 T5 AWD | [B5254T3] | 01.2006- |
| VOLVO | S40 2.5 T5 AWD | [B5254T7] | 01.2006- |
| VOLVO | V50 2.4 | [B5244S4] | 01.2004-12.2006 |
| VOLVO | V50 2.4 | [B5244S5] | 01.2004-12.2006 |
| VOLVO | V50 2.5 T5 | [B5254T3] | 01.2004-12.2006 |
| VOLVO | V50 2.5 T5 | [B5254T7] | 01.2004-12.2006 |
| VOLVO | V50 2.5 T5 AWD | [B5254T3] | 01.2004-12.2006 |
| VOLVO | V50 2.5 T5 AWD | [B5254T7] | 01.2004-12.2006 |
Reference Information
| 0001108402 | BOSCH |
| 0001108472 | BOSCH |
| 0986020860 | BOSCH |
| 101398 | KUHNER |
| 11020860 | EUROTEC |
| 114315 | CARGO |
| 12291 | EAI |
| 1374049 | FORD |
| 17979N | WAI / TRANSPO |
| 20401945BN | REAL |
| 220412 | ERA |
| 25-4003 | ELSTOCK |
| 332100 | LOGISTIK |
| 36050273 | VOLVO |
| 360502730 | VOLVO |
| 3M5T1-1000-EA | FORD |
| 42020860 | HERTH+BUSS |
| 5010458 | MEAT & DORIA |
| 6010549.0 | SANDO |
| 8020860 | FRIESEN |
| 810.522.093.010 | PSH |
| 810.522.093.210 | PSH |
| 810.522.093.215 | PSH |
| 8602924 | VOLVO |
| 86029240 | VOLVO |
| 8622742 | VOLVO |
| 88212154 | POWERMAX |
| 8EA011611-401 | HELLA |
| 8EA738258-451 | HELLA |
| 91-15-7224 | WILSON |
| 944280208600 | MAGNETI MARELLI |
| 9902 | CEVAM |
| CGB-54003 | AINDE |
| CS1398 | HC PARTS |
| CST10549AS | CASCO |
| DRT0860 | DELCO |
| DT1970 | DELCO |
| F032114315 | CARGO |
| LRS02331 | LUCAS |
| LRS2331 | LUCAS |
| MAV125490A | SIOM |
| MRS20860 | MAGNETI MARELLI |
| PRSW027 | 3EFFE |
| S12BH0497 | SIDAT |
| S12BH0497A2 | SIDAT |
| S-6266 | DIXIE |
| STB1398 | KRAUF |
| STR1499 | ELECTROLOG |
| STR50391 | WOODAUTO |
| STRW027 | 3EFFE |
| STX200421 | STARDAX |
| UD00855S | AS-PL |
Video/Publications
S0877S< Critical Notes >
Differences in solenoid connection types between S0059, S0533, S0877S
